1958 Corvette Specs

1958 Chevrolet Corvette brochure scan
To learn more about the 1958 Corvette, click here.

Body Specs

Wheelbase 101.85 inches
Front Track 57.00 inches
Rear Track 59.00 inches
Length 177.2 inches
Width
Including Bumpers / Moldings
72.8 inches
Width
Not Including Bumpers / Moldings
70.3 inches
Front Overhang 33.0 inches
Rear Overhang 42.2 inches
Height (at Windshield) 49.2 inches
Height (Loaded, Hard Top) 51.9 inches
Height (Loaded, Folding Top) 52.0 inches
Hood Opening Front (reverse alligator)
Finish (paint type) Lacquer
Turning Diameter 38.38 feet (right); 38.99 feet (left) wall - wall
36.55 feet (right); 36.93 feet (left) curb - curb
Steering gear ratio 16:1
Tire Size 6.70-15 4 Ply Rating
Three Speed Transmission 1st Gear 2.21:1
2nd Gear 1.32:1
3rd Gear 1.00:1
Four Speed Transmission Close Ratio 1st Gear 2.21:1
2nd Gear 1.66:1
3rd Gear 1.31:1
4th Gear 1.00:1
Axle Ratio 3.70:1; Optional: 4.11:1, 4.56:1
Automatic: 3.55:1
Transmission Synchromesh Three Speed: 2nd and 3rd Gears
Four Speed: All Four Gears


Weight

Shipping - Powerglide (Automatic) Transmission 2,889 lb.
Curb - Powerglide (Automatic) Transmission
Shipping + fuel (107 lb.),
water (38 lb.)
3,034 lb.
Loaded - Powerglide (Automatic) Transmission
(Two Passengers @ 150 lb. each)
3,344 lb.
Shipping - Three Speed (standard) Transmission 2,781 lb.
Curb - Three Speed (standard) Transmission
Shipping + fuel (107 lb.),
water (38 lb.)
2,926 lb.
Loaded - Three Speed (standard) Transmission
(Two Passengers @ 150 lb. each)
3,226 lb.
Optional Hard Top 55 lb.
Weight Differentials
Automatic (Powerglide) Transmission +104 pounds
Power Steering +25 pounds
Power Brakes +11 pounds


Engine Specs

Type: V8
Valve Location: In Head
Bore / Stroke: 3.875" / 3.00"
Displacement: 283 Cubic Inches
Compression Ratio: 9.5 : 1
Crankshaft Material: Forged Steel
Camshaft Material: Cast Alloy Iron
Oil Pump Type: Gear
Normal Oil Pressure 35 psi @ 2,000 RPM
Oil Pressure Gauge Electric
Crankcase Oil Capacity (less filter) 5 Quarts
Recommended Oil Grade Above 32°: SAE 20W or SAE 20
To 0°: SAE 10W or SAE 10W-30
Below 0°: SAE 5W or SAE 5W-20
Fuel Tank 16.4 Gallons
Fuel Filter Strainer
Fuel Pump Mechanical
Fuel Pressure 5¾ - 6¼ PSI
Carburetor Carter 3746384 Single 4 barrel
Carburetor
Optional dual four barrel carburetors Code 469
Carter 3744002 (front) / 3744004 (rear)
Cooling System Capacity 17 Quarts (with heater)
16 Quarts (without heater)
Cooling System Frontal Area 380 sq. in.
Radiator Cap Relief Pressure 6 ¼ - 7 ¾ PSI
Thermostat Type Choke
Thermostat Opening 160° F
Battery Delco 2 S1r 53-W (12 volt, nine plate)
53 Amp-hour @ 20 hour rate

Horsepower
Standard Engine 230 hp @ 4,600 RPM;
Torque: 300 lb-ft @ 3,000 RPM
Code 469A
(Two Four Barrel Carburetors)
245 hp @ 5,000 RPM;
Torque: 300 ft-lb. @ 3,800 RPM
Code 469C
(Two Four Barrel Carburetors, Special Camshaft)
270 hp @ 6,000 RPM;
Torque: 285 lb-ft @ 4,200 RPM
Code 579A Fuel Injection 250 hp @ 5,000 RPM;
Torque: 305 lb-ft @ 3,800 RPM
Code 579B
(Special Camshaft)
290 hp @ 6,200 RPM;
Torque: 290 lb-ft @ 4,400 RPM

Fuel Injection
Manufacturer Rochester Products
Model 7014900 (Code 579B, 283 hp)
Recommended Fuel Premium
Fuel Pump Mechanical
Fuel Pressure 5 ¼ - 6 ½ PSI
Inlet Manifold Cast Aluminum
Air Cleaner Type Dry
Air Meter Location Engine Left Side
Plenum Chamber Integral With Inlet Manifold
Ram Pipe Length 12 Inches
Fuel Induction Metered as Function of Air Flow
Air / Fuel Ratio Control Vacuum Sensitive Diaphragm Located on Air Flow Meter
Fuel Meter Pump Type Gear
Fuel Meter Pump Location In Fuel Meter Assembly
Fuel Meter Pump Drive Gear Driven by Flexible Shaft From Distributor
Fuel Meter Pump Pressure 300 PSI
Injection Nozzles Quantity 8
Injection Nozzles Material Brass
Injection Nozzles Location Mounted on Inlet Manifold Above Intake Ports
Injection Nozzles Orifice Size - Fuel .0118 inch
Injection Nozzles Insulation Bakelite
Automatic Choke Type Electric, Time Temperature Type
Automatic Choke Location On Air Meter Assembly
Automatic Choke Current Draw 2 amps @ 70°
Automatic Choke Fast Idle Cam Yes

Ignition System
Coil Delco-Remy 1115091 (FI Engines: 11151007)
Coil current rating 4 amps (engine stopped)
1.8 amps (engine running)
Breaker Gap .018"
Ignition Timing 4° BTDC @ 600 RPM idle
Ignition Timing Centrifugal Advance 28 ° @ 3,700 RPM
Ignition Timing Vacuum Advance
Standard Engine
15° @ 15.5 inches Hg
Ignition Timing Vacuum Advance
Two Four Barrel Carburetor
Fuel Injection with Special Camshaft
None
Spark Plug AC 46
Spark Plug Thread 14 mm.
Spark Plug Torque 20 - 25 lb.-ft.
Spark Plug Gap .035 inch
Firing Order 1-8-4-3-6-5-7-2

1958 Corvette Options

RPO Description Production Price
