To learn more about the 2007 Corvette, click here.
2007 Corvette Specs
Body Specs |
|||||
| Model Code: |
1YY07 (Coupe)
1YY67 (Convertible) 1YY87 (Z06) |
||||
| Wheelbase - Coupe, Convertible, Z06: | 105.7 inches / 2,685 mm | ||||
| Length - Coupe, Convertible: | 174.60 inches / 4,435 mm | ||||
| Length - Z06: | 175.60 inches / 4,460 mm | ||||
| Width, not including mirrors - Coupe, Convertible: | 72.60 inches / 1,844 mm | ||||
| Width, not including mirrors - Z06: | 75.90 inches / 1,928 mm | ||||
| Height - Coupe, Convertible, Z06: | 49.00 inches / 1,245 mm | ||||
| Front Track: | 62.10 inches / 1,677mm | ||||
| Rear Track: | 60.70 inches / 1,542 mm | ||||
| Min. Ground Clearance: | 3.7 inches | ||||
| Head Room: | Coupe: 38 inches / 962.0 mm | ||||
| Shoulder Room: | 55 inches / 1,397 mm | ||||
| Hip Room: | 54 inches / 1,371 mm | ||||
| Leg Room: | 43 inches / 1,092 mm | ||||
| Cargo Capacity: |
22 Cubic Feet / 634 Liters (Coupe, Z06)
11 Cubic Feet / 295 Liters (Convertible, top up) 5 Cubic Feet / 144 Liters (Convertible, top down) |
||||
| Tire Size: |
P245/40ZR-18 (Front)
P285/35ZR-19 (Rear) (Goodyear Eagle F1 GS, Extended Mobility) |
||||
| Tire Size, Z51 Sport Package: |
P245/40ZR-18 (Front)
P285/35ZR-19 (Rear) (Goodyear Eagle F1 GS, F1 Supercar Extended Mobility) |
||||
| Tire Size, Z06: |
P275/35ZR-18 (Front)
P325/30ZR-19 (Rear) (Goodyear Eagle F1 GS, F1 Supercar Extended Mobility) |
||||
| Wheel Size - Coupe, Convertible: |
18 inch x 8.5 inch (Front)
19 inch x 10 inch (Rear) |
||||
| Wheel Size - Z06: |
18 inch x 9.5 inch (Front)
19 inch x 12 inch (Rear) |
||||
| Wheel Type: | Cast Aluminum, Front and Rear | ||||
| Recommended Tire Inflation: | 30 PSI Front / Rear | ||||
| Manual Six Speed Transmission: |
1st Gear 2.66:1
2nd Gear 1.78:1 3rd Gear 1.30:1 4th Gear 1.00:1 5th Gear .74:1 6th Gear .50:1 Reverse Gear 2.90:1 Final Drive Ratio 3.42 |
||||
| Tremec T56 Manual Six Speed Transmission - Z51 Sport Package: |
1st Gear 2.97:1
2nd Gear 2.07:1 3rd Gear 1.43:1 4th Gear 1.00:1 5th Gear .71:1 6th Gear .57:1 Reverse Gear 3.28:1 Final Drive Ratio 3.42 |
||||
| Hydra-Matic 2006 6L80 (MYC) Six Speed: |
1st Gear 4.03:1
2nd Gear 2.36:1 3rd Gear 1.53:1 4th Gear 1.15:1 5th Gear 0.85:1 6th Gear 0.67:1 Reverse Gear 3.06:1 Final Drive Ratio 2.56 |
||||
| Standard Fuel Tank Capacity: | 18.0 Gallons / 68.0 Liters | ||||
| Battery, Cold Cranking Amps: | 590 | ||||
| Battery Replacement Model Number: | 86-3YR | ||||
| EPA Fuel Economy: |
Manual Transmission (Coupe, Convertible)
16 MPG (City) / 26 MPG (Highway) / 19 MPG (Combined) Automatic Transmission (Coupe, Convertible) 15 MPG (City) / 25 MPG (Highway) / 19 MPG (Combined) Manual Transmission (Z06) 15 MPG (City) / 25 MPG (Highway) / 19 MPG (Combined) |
||||
| Maximum Cruising Range - Coupe, Convertible: |
534.8 Miles (Manual Transmission)
477.5 Miles (Automatic Transmission) |
||||
| Weight: |
3,199 lbs / 1,451 kg (Convertible)
3,179 lbs / 1,442 kg (Coupe) 3,130 lbs / 1,419 kg (Z06) |
||||
| Weight Distribution: | 51% Front, 49% Rear | ||||
|
Passenger Compartment Air Filter Element:
(Coupe, Convertible, Z06) |
10345066 | ||||
|
|
| Designation: |
LS2 (Coupe, Convertible)
LS7 (Z06) |
| Type: | 90° V8, Pushrod, OHV (overhead Valve) |
| Displacement - Coupe, Convertible: | 6.0 liters / 364 cubic inches (LS2) |
| Displacement - Z06: | 7.0 liters / 427 cubic inches (LS7) |
| Bore / Stroke - Coupe, Convertible: | 4.00 inches (101.62 mm) / 3.62 inches (92.0 mm) |
| Bore / Stroke - Z06: | 4.125 inches (104.8 mm) / 4.00 inches (101.6 mm) |
| Horsepower: |
400 hp @ 6,000 RPM (Coupe, Convertible LS2)
505 hp @ 6,300 RPM (Z06 LS7) |
| Torque: |
400 lbs. - ft. @ 4,400 RPM (Coupe, Convertible LS2)
470 lbs. - ft. @ 4,800 RPM (Z06 LS7) |
| Fuel Induction System: | Sequential Fuel Injection |
| Fuel Requirement - Coupe, Convertible: | Premium Recommended |
| Fuel Requirement - Z06: | Premium Required |
| Redline (RPM): | 6,500 |
| Compression Ratio - Coupe, Convertible: | 10.9:1 |
| Compression Ratio - Z06: | 11.0:1 |
| Alternator: | 50 Amps (idle), 120 Amps Maximum |
| Cylinder Head Material: | Cast Aluminum |
| Cylinder Block Material: | Cast Aluminum |
| Engine Oil Capacity - Coupe, Convertible: |
5.5 Quarts, with filter
5.0 Quarts, without filter |
| Engine Oil Capacity - Z06: |
8.0 Quarts, with filter
7.5 Quarts, without filter |
| Recommended Oil: | 5W/30 Mobil 1 Synthetic or Equivalent |
| Recommended Oil Change Interval: | 15,000 miles or One Year, under normal use |
| Engine Oil Filter - Coupe, Convertible: | AC Delco Tyoe PF46 |
| Engine Oil Filter - Z06: | AC Delco Tyoe PF48 |
| Engine Coolant Capacity: | 12.6 Quarts (Coupe, Convertible, Z06) |
| Radiator Core Material: | Aluminum |
| Fill Cap Pressure Rating: | 15 PSI |
| Fill Cap Pressure Test Rating (Max.): | 20 PSI |
| Emission Control System: |
|
| Air Cleaner Filter - Coupe, Convertible: |
GM p/n 10342024
AC Delco p/n A2945C |
| Air Cleaner Filter - Z06: |
GM p/n 1576148
AC Delco p/n A3077C |
| Coolant Surge Cap: |
15 PSI
GM P/N 10296465 |
| Assembly Site: | Romulus, MI |
|
|
| Spark Plug Model - Coupe, Convertible: | AC P/N 41-985; GM Part No. 12571164 |
| Spark Plug Model - Z06: | AC P/N 41-104; GM Part No. 12571165 |
| Spark Plug Thread: | 14.0 mm |
| Spark Plug Tightening Torque: | 11 lb. ft / 15 N-m |
| Spark Plug Gap: | 1.0 mm (0.040 inch) |
| Spark Plug Wire Resistance: | 188 - 312 Ω |
|
|
| Structure / Frame: | Integral Perimeter Frame with Center Backbone / All Welded Steel Body |
| Suspension - Front: | Independent SLA (Sort Long Arm) double wishbone cast aluminum upper and lower control arms, transverse mounted composite leaf spring, monotube shock absorber. |
| Suspension - Rear: | Independent SLA (Sort Long Arm) double wishbone cast aluminum upper and lower control arms, transverse mounted composite leaf spring, monotube shock absorber. |
| Steering: | Speed sensitive, magnetic power assisted rack and pinion |
| Steering Ratio: | 16.1:1 |
| Steering Turns, Lock to Lock: | 2.66 |
| Turning Circle, Curb to Curb: | 12.0 M / 39.4 ft. |
Brake Specs |
|
| Type: | Power Assisted, Four Wheel Vented Disc with Four Wheel ABS |
| Rotor, Front: |
Outer Working Diameter: (325 mm.) 12.8 inches
Thickness: (32 mm.) 1.26 inches |
| Rotor, Rear: |
Outer Working Diameter: (305 mm.) 12.0 inches
Thickness: (26 mm.) 1.0 inches |
| Rotor, Front - Z51 Performance Package: |
Diameter: (340 mm.) 13.4 inches
Thickness: (32 mm.) 1.26 inches |
| Rotor, Rear - Z51 Performance Package: |
Diameter: (330 mm.) 13.0 inches
Thickness: (26 mm.) 1.0 inches |
| Rotor, Front - Z06: |
Diameter: (355 mm.) 14.0 inches
Thickness: (32 mm.) 1.3 inches |
| Rotor, Rear - Z06: |
Diameter: (340 mm.) 13.4 inches
Thickness: (26 mm.) 1.0 inches |
2007 Corvette Options
| RPO | Description | Production | Price |
| 19U | LeMans Blue exterior paint | 3,854 (9.50%) | $300.00 |
| 2LT* | Equipment Group - Coup | 2,606 (6.42%) | $1,495.00 |
| 2LZ** | Preferred Equipment Group - Z06 | 6,487 (15.99%) | $3,485.00 |
| 3LT | Preferred Equipment Group - Convertible | 9,533 (23.50%) | $5,540.00 |
| 3LT*** | Preferred Equipment Group - Coup | 11,934 (29.42%) | $4,945.00 |
| 45U | Velocity Yellow exterior paint | 3,755 (9.26%) | $750.00 |
| 80U | Monterey Red exterior paint | 5,023 (12.38%) | $750.00 |
| 83U | Atomic Orange exterior paint | 3,790 (9.34%) | $750.00 |
| C2L | Dual Removable Roof Panels (coup) | 3,558 (8.77%) | $1,400.00 |
| CC3 | Removable Roof Panel, transparent (coup) | 4,370 (10.77%) | $750.00 |
| D30 | Non-recommended color / trim / top combo | 126 (0.31%) | $590.00 |
| F55 | Magnetic Selective Ride Control (coupe and convertible) | 5,619 (13.85%) | $1,995.00 |
| MX0 | Six-speed Paddle Shift Automatic Transmission (coupe and convertible) | 22,422 (55.28%) | $1,250.00 |
| Q44 | Competition Gray Aluminum Wheels (Z06) | 545 (1.34%) | $395.00 |
| QG7 | Polished Aluminum Wheels (coupe and convertible) | 3,461 (8.53%) | $1,295.00 |
| QL9 | Polished Aluminum Wheels (Z06) | 3,459 (8.53%) | $1,495.00 |
| QX1 | Competition Gray Aluminum Wheels (coupe and convertible) | 1,091 (2.69%) | $395.00 |
| QX3 | Chrome Aluminum Wheels (coupe and convertible) | 19,850 (48.94%) | $1,850.00 |
| R8C | Corvette Museum Delivery | 1,104 (2.72%) | $490.00 |
| U3U | AM/FM, CD, Navigation with XM and Bose | 20,653 (50.92%) | $1,750.00 |
| UE1 | OnStar System (3LT or 2LZ required) | 18,074 (44.56%) | $695.00 |
| US9 | AM/FM 6-CD with XM and Bose (with 1LZ) | 9,970 (24.58%) | $1,890.00 |
| Z51 | Performance Package (coupe and convertible) | 13,696 (33.77%) | $1,695.00 |
|
Total Production:
40,561
Notes: Base Corvette Coupe with 346 cu. in. 400 hp engine and six speed manual transmission: $44,995.00. |
|||
2007 Packages |
||||
| RPO | Description | Contains | Production | Price |
| 2LZ |
Z06 Preferred Equipent Group |
Includes side air bags, power telescopic steering column, auto dimming mirrors, heated seats, RPO U2K, cargo net, luggage shade and homelink. | 6,487 (15.99%) | $3,485 |
| 3LT |
Preferred Equipment Group Coupe |
Includes 2LT items + heads-up display, power telescopic steering column, auto dimming mirrors, memory package, heated seats, RPO US9 radio, compass and homelink. | 11,934 (29.42%) | $4,945 |
| 3LT |
Preferred Equipment Group Convertible |
Includes 2LT items + heads-up display, power telescopic steering column, auto dimming mirrors, memory package, heated seats, RPO US9 radio, compass and homelink. | 9,533 (23.50%) | $5,540 |
Colors
| Code | Exterior | Quantity | Interior | Soft Top | |
| Atomic Orange | 3,790 (9.34%) | Ebony / Cashmere / Titanium Gray | |||
| 10 | Arctic White | 2,387 (5.88%) | Red / Ebony / Cashmere / Titanium Gray | ||
| 19 | LeMans Blue | 3,854 (9.50%) | Ebony / Cashmere / Titanium Gray | ||
| 41 | Black | 9,526 (23.49%) | Red / Ebony / Cashmere / Titanium Gray | ||
| 45 | Velocity Yellow | 3,755 (9.26%) | Ebony / Cashmere / Titanium Gray | ||
| 67 | Machine Silver | 5,518 (13.60%) | Red / Ebony / Cashmere / Titanium Gray | ||
| 74 | Victory Red | 6,708 (16.54%) | Red / Ebony / Cashmere / Titanium Gray | ||
| 80 | Monterey Red | 5,023 (12.38%) | Red / Ebony / Cashmere / Titanium Gray | ||
|
Notes: All colors available with Z06 except codes 10 and 80. Le Mans Blue, Monterey Red, Atomic Orange and Velocity Yellow are extra-cost options. |
|||||
