To learn more about the 1987 Corvette, click here.
1987 Corvette Specs
Body Specs |
|
| Wheelbase | 96.2 inches |
| Overhang (Front) | 40.5 inches |
| Overhang (Rear) | 39.7 inches |
| Front Track | 59.6 inches |
| Rear Track | 60.4 inches |
| Length | 176.5 inches |
|
Ground Clearance
Differential to Ground |
6.8 inches |
|
Ground Clearance
Front Bumper to Ground |
5.1 inches |
|
Ground Clearance
Rear Bumper to Ground |
13.9 inches |
| Minimum Ground Clearance |
4.7 inches
(Measured at Catalytic Converter) |
| Overall Height |
46.7 inches (Coupe)
46.4 inches (Convertible) |
| Rocker Panel to Ground (Front) | 6.9 inches |
| Rocker Panel to Ground (Rear) | 6.9 inches |
| Cargo Capacity |
100 lbs. / (Coupe and Convertible)
6.6 cubic feet (Convertible) Liftover Height: 35.75 Inches (Coupe) Cargo Length at Floor: 33.0 inches (Coupe) |
| Cowl Height | 33.4 inches |
| Windshield Slope Angle | 64.7° |
| Effective Head Room | 36.4 inches |
| Shoulder Room | 54.1 inches |
| Hip Room | 49.3 inches |
| Tire Size |
P255/50VR-16 B/W
(Goodyear Eagle VR50, Unidirectional) |
| Wheel Size |
16" x 8.5" (Front and Rear)
With Z51 Performance Handling Package Front / Rear: 16" x 9.5" |
| Recommended Tire Inflation | 35 PSI Front / Rear |
| Manual Four Speed Transmission |
1st Gear 2.88:1
2nd Gear 1.91:1 (1.30:1 Overdrive) 3rd Gear 1.34:1 (0.91:1 Overdrive) 4th Gear 1.00:1 (0.68:1 Overdrive) Reverse Gear 2.78:1 |
| Turbo Hydra-Matic (Automatic) Transmission |
1st Gear 3.06:1
2nd Gear 1.63:1 3rd Gear 1.00:1 4th Gear 0.70:1 Reverse Gear 2.29:1 |
|
Turbo Hydra-Matic (Automatic) Transmission
Lubricant |
Dextron II
8.0 Pints |
|
Maximum Uphill Speed
(Wide Open Throttle) |
1 > 2: 43 MPH
2 > 3: 79 MPH 3 > 4: 116 MPH |
|
Differential Lubricant Type
Manual Transmission |
GL-5
SAE 80W, SAE 80W-90 |
| Axle Ratio |
3.07:1 (Manual Transmission)
2.59:1, 2.73:1 (Automatic Transmission) |
| Standard Fuel Tank Capacity | 20 Gallons |
| Steering Ratio |
15.5:1
13.0:1 (Performance Handling Package, RPO Z51) |
| Steering Wheel Diameter | 14.5 inches |
|
|
| Automatic Coupe |
City: 15
Highway: 23 Combined: 17 |
| Automatic Convertible |
City: 15
Highway: 23 Combined: 17 |
|
|
| Model 1YY07 Sport Coupe |
Curb Mass with Four Speed Manual Transmission
|
| Model 1YY67 Convertible |
Curb Mass with Four Speed Manual Transmission
|
|
Curb Weight: The calculated weight of a vehicle with standard equipment, only as designed with the additional load of oils, lube, coolant and fuel filled to capacity.
Shipping Weight: Same as base curb weight except only 3 gallons of gasoline. |
|
|
|
|
|
|
|
|
Removeble Plastic Roof Panel
(RPO CC3) |
-4.0 lb.
(-0.9 lb. Front; -3.1 lb. Rear) |
|
Power Door Lock System
(RPO AU3) |
+1.8 lb.
(+0.9 lb. Front; +0.9 lb. Rear) |
|
Electric Defogger System
Rear Window and Side Mirror (RPO Z6A) |
+0.8 lb.
(+0.4 lb. Front; +0.4 lb. Rear) |
|
Performance Handling Package
(RPO Z51) |
+35.7 lb.
(+25.1 lb. Front; +10.6 lb. Rear) |
|
Automatic Speed Control
With Resume Speed (RPO K34) |
+2.7 lb.
(+2.3 lb. Front; +0.4 lb. Rear) |
|
Radio AM / FM Stereo (ETR)
with Cassette (RPO UM6) Includes Power Rear Antenna plus Two Front and Rear Speakers |
+0.8 lb.
(+0.4 lb. Front; +0.4 lb. Rear) |
|
Delco-Bose
Premium Audio System (RPO UU8) |
+15.4 lb.
(+4.4 lb. Front; +11.0 lb. Rear) |
| Radio Delete (RPO UL5) |
-11.0 lb.
(-5.3 lb. Front; -5.7 lb. Rear) |
|
Full Feature Sports Seats
(RPO AQ9) |
+16.3 lb.
(+7.5 lb. Front; +8.8 lb. Rear) |
|
Automatic Transmission
(RPO MM4) |
+13.6 lb.
(+10.1 lb. Front; +3.5 lb. Rear) |
|
Custom Two Tone Paint
(RPO D84) |
+0.8 lb.
(+0.4 lb. Front; +0.4 lb. Rear) |
|
|
| Type: | 90° V8 - OHV |
| Valve Location: | In Head |
| Bore / Stroke: | 4.00" / 3.48" |
| Displacement: |
350 Cubic Inches
(5.7 Liters) |
| Compression Ratio: | 9.5:1 |
| Cylinder Head Material: | Aluminum |
| Cylinder Block Material: | Cast Alloy Iron |
| Oil Pump Type: | Gear |
| Cooling System Capacity |
14.65 Quarts (Manual Transmission)
14.51 Quarts (Automatic Transmission) |
| Radiator Cap Relief Pressure | 18.0 PSI |
| Battery |
12 volt - 630 Cold Cranking Amps (CCA)
54 Amp-hours |
| Alternator |
Delco-Remy
105 Amps |
|
Fuel System |
|
| Type | Electronic Fuel Injection - Tuned Port Injection |
| Fuel Pump | Electric, Dual Turbine - In Fuel Tank |
| Point of Injection | Fuel Injectors at Inlet Ports |
| Flow | Pulse |
|
Horsepower |
|
| Standard Engine (350 cubic inch) |
240 hp @ 4,000 RPM;
Torque: 345 lb-ft @ 3,200 RPM |
|
Ignition System |
|
| Spark Plug |
FR3LS
Make: AC |
| Spark Plug Thread | M14 x 1.25 |
| Spark Plug Gap | .035 inch |
| Spark Plug Tightening Torque | 18 - 22 lb. - ft. |
|
Brakes |
|
| Type | Disc with Sliding Head Caliper - low drag |
| Effective Area |
27.0 Square Inches (Front)
18.3 Square Inches (Rear) |
| Gross Lining Area |
27.0 Square Inches (Front)
18.3 Square Inches (Rear) |
| Swept Area |
96.4 Square Inches (Front)
87.5 Square Inches (Rear) |
| Rotor |
Outer Working Diameter: 11.5 inches
Inner Working Diameter: 8.42 Inches (Front), 8.75 Inches (Rear) Type and Material: Vented, Gray Cast Iron (Front) Damped Iron (Rear) |
1987 Corvette Options
| RPO | Description | Production | Price |
| 24S | Removable Roof Panel, blue tint (coupe) | 12,021 (34.24%) | $595.00 |
| 4001ZA | Malcolm Konner Special Edition (coupe) | 50 (0.14%) | $500.00 |
| 64S | Removable Roof Panel, bronze tint (coupe) | 7,819 (22.27%) | $595.00 |
| AG9 | Power Driver Seat | 33,983 (96.79%) | $225.00 |
| AQ9 | Sports Seats, leather | 13,372 (38.09%) | $1,025.00 |
| AR9 | Base Seats, leather | n/a | $400.00 |
| AU3 | Power Door Locks | 34,215 (97.45%) | $175.00 |
| B4P | Radiator Booster Fan | 8,216 (23.40%) | $75.00 |
| B4Z | Custom Feature Package | 4,832 (13.76%) | $195.00 |
| C2L | Dual Removable Roof Panels (coupe) | 6,242 (17.78%) | $895.00 |
| C68 | Electronic Air Conditioning Control | 16,646 (47.41%) | $150.00 |
| D84 | Two-Tone Paint (coupe) | 3,897 (11.10%) | $428.00 |
| FG3 | Delco-Bilstein Shock Absorbers | 5,521 (15.73%) | $189.00 |
| G92 | Performance Axle Ratio, 3.07:1 | 4,879 (13.90%) | $22.00 |
| K34 | Cruise Control | 34,197 (97.40%) | $185.00 |
| KC4 | Engine Oil Cooler | 7,394 (21.06%) | $110.00 |
| MM4 | 4-Speed Manual Transmission | 6,835 (19.47%) | n/a |
| NN5 | California Emission Requirements | 5,697 (16.23%) | $99.00 |
| UL5 | Radio Delete | 166 (0.47%) | $-256.00 |
| UM6 | AM-FM Stereo Cassette | 2,039 (5.81%) | $122.00 |
| UU8 | Stereo System, Delco-Bose | 32,478 (92.51%) | $895.00 |
| V01 | Heavy-Duty Radiator | 10,423 (29.69%) | $40.00 |
| Z51 | Performance Handling Package (coupe) | 12,821 (36.52%) | $470.00 |
| Z6A | Rear Window + Side Mirror Defoggers (coupe) | 21,837 (62.20%) | $165.00 |
|
Total Production:
35,109
Notes: Base Corvette Coupe with 350 cu. in. 235 hp engine and four speed automatic transmission: $27,027.00. |
|||
Colors
| Code | Exterior | Quantity | Interior | Soft Top | |
| 13 | Silver Metallic | 1,209 (3.44%) | Graphite / Medium Gray | Black / White | |
| 13 / | Silver / Gray | 1,049 (2.99%) | Graphite / Medium Gray / Red | ||
| 18 | Medium Gray Metallic | 1,603 (4.57%) | Graphite / Medium Gray / Red | Black / White | |
| 18 / | Gray / Black | 1,138 (3.24%) | Graphite / Medium Gray | ||
| 20 | Medium Blue Metallic | 128 (0.36%) | Blue / Graphite | Black / White | |
| 35 | Yellow | 1,464 (4.17%) | Graphite | Black / White | |
| 40 | White | 4,176 (11.89%) | Blue / Bronze / Graphite / Medium Gray / Red / Saddle | Black / Saddle / White | |
| 40 / | White / Silver | 693 (1.97%) | Graphite / Medium Gray | ||
| 41 | Black | 5,464 (15.56%) | Graphite / Medium Gray / Red / Saddle | Black / Saddle / White | |
| 53 | Gold Metallic | 777 (2.21%) | Graphite / Saddle | Black / Saddle | |
| 59 | Silver Beige Metallic | 1,383 (3.94%) | Bronze / Graphite | Black | |
| 59 / | Silver Beige / Medium Bro | 1,014 (2.89%) | Bronze | ||
| 66 | Copper Metallic | 4 (0.01%) | Graphite / Saddle | Black / Saddle | |
| 69 | Medium Brown Metallic | 488 (1.39%) | Bronze / Saddle | Saddle | |
| 74 | Dark Red Metallic | 5,002 (14.25%) | Graphite / Saddle | Black / Saddle / White | |
| 81 | Bright Red | 9,466 (26.96%) | Graphite / Red / Saddle | Black / Saddle / White | |
| Spec | Silver Beige / Black | 50 (0.14%) | Graphite | ||
