1967 Corvette Specs
Body Specs |
||
| Wheelbase | 98.00 inches | |
| Overhang (Front) | 31.9 inches | |
| Overhang (Rear) | 45.2 inches | |
| Front Track | 56.8 inches | |
| Rear Track | 57.6 inches | |
| Length | 175.1 inches | |
| Front Fender Width | 69.6 inches (Maximum) | |
| Rear Fender Width | 67.3 inches | |
| Height (Design) |
49.6 inches (Coupe)
49.8 inches (Soft, Hard Top) |
|
| Hood (at Rear) to Ground | 34.8 inches | |
| Rocker Panel to Ground (Front) | 8.0 inches | |
| Rocker Panel to Ground (Rear) | 8.0 inches | |
| Bottom of Door to Ground (Open) | 13.5 inches | |
| Bottom of Door to Ground (Closed) | 12.5 inches | |
| Windshield Slope Angle | 56° | |
| Body Zero to Ground (Front) | 7.7 inches | |
| Body Zero to Ground (Rear) | 7.7 inches | |
| Headlamp to Ground | 24.4 inches | |
| Tail Lamp to Ground | 21.2 inches | |
| Hood Length at Centerline | 46.7 inches | |
| Body Upper Structure Length at Centerline |
Coupe: 77.9 inches
Soft Top: 66.8 inches Hardtop: 69.2 inches |
|
| Front Bumper to Ground | 10.3 inches | |
| Rear Bumper to Ground | 10.8 inches | |
| Oil Pan to Ground | 6.0 inches | |
| Front Suspension to Ground | 8.0 inches | |
| Flywheel Housing to Ground | 5.9 inches | |
| Exhaust System to Ground | 5.0 inches | |
| Rear Axle Differential to Ground | 7.8 inches | |
| Spare Tire Well to Ground | 6.1 inches | |
| Minimum Running Ground Clearance | 5.0 inches | |
| Windshield Glass Area | 789.7 inches | |
| Finish (paint type) | Lacquer | |
| Steering gear ratio | 16:1 | |
| Steering Wheel Turns |
Manual: 3.4
Power: 2.92 |
|
| Power Steering Fluid Capacity | 2.3 Pints | |
| Steering Wheel Type | Deep Dish | |
| Steering Wheel Diameter | 16.0 inches | |
| Tire Size | 7.75-15 4 Ply Rating | |
| Recommended Tire Inflation | 24 psi, All Wheels | |
| Wheels, Regular Production |
Size: 15 x 5.5
Attachment to Hub: Five Hex nuts |
|
| Wheels, RPO N89 |
Size: 15 x 6 Cast Aluminum
Method of Retention: Five Hex Nuts, 4.75 inch Diameter Bolt Circle |
|
| Three Speed Transmission |
1st Gear 2.54:1
2nd Gear 1.50:1 3rd Gear 1.00:1 Reverse Gear 2.63:1 |
|
| Automatic (Powerglide) Transmission |
Drive: 1.76:1 & 1:1
Low and Reverse: 1.76:1 |
|
| Lubricant Capacity | 3 Quarts | |
|
Four Speed M20 Transmission
(Standard, L79, L36, L68 engines) |
1st Gear 2.52:1
2nd Gear 1.88:1 3rd Gear 1.47:1 4th Gear 1.00:1 Reverse Gear 2.59:1 |
|
|
Close Ratio Four Speed M21 Transmission
(L36, L68, L71 engines) |
1st Gear 2.20:1
2nd Gear 1.64:1 3rd Gear 1.27:1 4th Gear 1.00:1 Reverse Gear 2.26:1 |
|
| Transmission Lubricant Type |
Military MIL-L-2105-B
SAE 80 |
|
| Lubricant Capacity |
Three Speed: 2 Quarts
Four Speed: 2.5 Quarts |
|
| Differential Lubricant Type |
Military MIL-L-2105-B
SAE 80 |
|
| Differential Lubricant Capacity | 3.7 pints | |
| Axle Ratio |
Standard: 3.36:1
Optional: 3.08:1 L36, L68, L79 Engines: 3.36:1, 3.55:1, 4.11:1 L71 Engine: 3.36:1, 3.55:1, 3.70:1, 4.11:1 |
|
| Transmission Synchromesh |
Three Speed: 2nd and 3rd Gears
Four Speed: All Four Gears |
|
| Standard Fuel Tank Capacity | 20 Gallons | |
| Fuel Tank Code (RPO N03) | 36.0 Gallons (Coupe Only) | |
|
||
| Model 19467 Convertible |
|
|
| Model 19437 Sport Coupe |
|
|
|
Shipping Weight: Weight of basic vehicle with regular equipment and grease and oil. Weight of gasoline and water not included.
Curb Weight: Weight of empty vehicle ready to drive. Shipping weight plus the weight of gasoline and water. |
||
|
|
||
| Three Speed Manual Transmission, 300 Horsepower Standard Engine |
Standard Engine: 3,456 lb.
Weight / Horsepower: 11.52 |
|
| Four Speed Manual Transmission, 300 Horsepower Standard Engine |
Standard Engine: 3,451 lb.
Weight / Horsepower: 11.50 |
|
| Four Speed Manual Transmission |
350 Horsepower L79 Engine: 3,451 lb.
Weight / Horsepower: 9.86 |
|
| Four Speed Manual Transmission |
390 Horsepower L36 Engine: 3,626 lb.
Weight / Horsepower: 9.30 |
|
| Four Speed Manual Transmission |
400 Horsepower L68 Engine: 3,626 lb.
Weight / Horsepower: 9.07 |
|
| Four Speed Manual Transmission |
435 Hosepower L71 Engine: 3,626 lb.
Weight / Horsepower: 8.34 |
|
|
Two Speed Powerglide
Automatic Transmission |
300 Horsepower
Standard Engine: 3,457 lb. Weight / Horsepower: 11.52 |
|
|
Two Speed Powerglide
Automatic Transmission |
390 Horsepower L36 Engine: 3,632 lb.
Weight / Horsepower: 9.31 |
|
|
Two Speed Powerglide
Automatic Transmission |
400 Horsepower L68 Engine: 3,632 lb.
Weight / Horsepower: 9.08 |
|
|
|
||
| Power Windows (RPO A31) | +5 lb. | |
| Auxiliary Top (RPO C07) | +49 lb. | |
| Heater Delete (RPO C48) | -20 lb. | |
| Air Conditioning (RPO C60) | +93 lb. | |
| Power Brakes (RPO J50) | +12 lb. | |
| Power Brakes (RPO J56) | 12 lb. | |
| Aluminum Cylinder Heads (RPO L89) | -73 lb. | |
| Four Speed Transmission (RPO M20) | -5 lb. | |
| Powerglide (Automatic) Transmission (RPO M35) | +1 lb. | |
| Power Steering (RPO N40) | +21 lb. | |
| Radio AM - FM Pushbutton (RPO U69) | +21 lb. | |
|
327 cubic inch Engine
350 Horsepower (RPO L79) |
-8 lb. | |
|
427 cubic inch Engine
390 Horsepower (RPO L36) |
+215 lb. | |
|
427 cubic inch Engine
400 Horsepower (RPO L68) |
+151 lb. | |
|
427 cubic inch Engine
435 Horsepower (RPO L71) |
+149 lb. | |
|
|
| Type: | V8 |
| Valve Location: | In Head |
| Bore / Stroke: |
4.00" / 3.25" (Standard, L79 327 Cubic Inch)
4.25" / 3.76" (L36, L72 427 Cubic Inch) |
| Displacement: |
Standard, L79: 327 Cubic Inches
L36, L68, L71: 427 Cubic Inches |
| Compression Ratio: |
10.0:1 (Standard Engine)
10.25:1 (L36, L68 Engines) 11.0:1 (L71, L79 Engines) |
| Rocker Arms | Stamping, Steel |
| Rocker Arm Ratio | 1.5:1 |
|
Valve Train Lash, Inlet / Exhaust
Hydraulic Lifters |
Zero |
|
Valve Train Lash, Inlet / Exhaust
Mechanical Lifters (RPO L72) |
Inlet: .024 inch
Exhaust: .028 inch |
| Crankshaft Material: | Forged Steel |
| Camshaft Material: | Cast Alloy Iron |
| Oil Pump Type: | Gear |
| Normal Oil Pressure |
30 - 45 psi @ 1,500 RPM
50 - 75 psi @ 2,000 RPM |
| Oil Pressure Gauge | Mechanical |
| Crankcase Oil Capacity, Standard, L79 Engines |
4 Quarts, Less Filter
5 Quarts, With Filter |
| Crankcase Oil Capacity, L36, L68, L71, L88 and L89 Engines |
5 Quarts, Less Filter
6 Quarts, With Filter |
| Recommended Oil Grade |
Above 32°: SAE 20W, SAE 20 or SAE 10W-30
To 0°: SAE 10W or SAE 10W-30 Below 0°: SAE 5W or SAE 5W-20 Alternate: SAE 5W-30 can be used for 5W, 5W-20 or 10W-30 |
| Carburetor |
Standard, 350 Horsepower Engine:
Holley 3906631 Single 4 barrel L36 390 Horsepower Engine: Holley 3906633 Single 4 barrel L68 400 Horsepower, L71 435 Horsepower Engines: Holley 3902355 Primary; 3902353 Secondary |
| Fuel Filter | Strainer |
| Fuel Pump | Mechanical |
| Fuel Pressure | 5¼ - 6½ PSI |
| Cooling System Capacity |
327 cubic inch Engines
16 Quarts (with heater) 15 Quarts (without heater) 427 cubic inch Engines 23 Quarts (with heater) 22 Quarts (without heater) |
| Thermostat Type | Choke |
| Radiator Cap Relief Pressure | 15 +/- 1 PSI |
| Battery |
12 volt
61 Amp hr. @ 20 hr. 6 cells / 66 Plates |
| Thermostat Opening | 177° - 182° F |
| Compression Pressure |
160 PSI (All but L72 Engine)
170 PSI (L72 Engine) |
|
Horsepower |
|
| Standard Engine |
300 hp @ 5,000 RPM;
Torque: 360 lb-ft @ 3,400 RPM |
| RPO L79 |
350 hp @ 5,800 RPM;
Torque: 360 ft-lb. @ 3,600 RPM |
| RPO L36 (427 cubic inch) |
390 hp @ 5,200 RPM;
Torque: 460 lb-ft @ 3,600 RPM |
| RPO L68 (427 cubic inch) |
400 hp @ 5,400 RPM;
Torque: 460 lb-ft @ 3,600 RPM |
| RPO L71 (427 cubic inch) |
435 hp @ 5,800 RPM;
Torque: 460 lb-ft @ 4,000 RPM |
|
Ignition System |
|
| Coil |
Delco-Remy 1115202 Base, L79;
1115264 L36, L68; 1111141 L36; 1115210 L71 |
| Coil current rating |
4 amps (engine stopped)
1.8 amps (engine running) |
| Breaker Gap | .019" (New) |
|
Ignition Timing
Initial Design Setting |
6° @ 500 RPM (Standard Engine)
10° @ 700 RPM (L79 Engine) 4° @ 550 RPM (L36, L68 Engines) 4° @ 750 RPM (L71 Engine) |
| Ignition Timing Centrifugal Advance |
Begins: 900 RPM (All Engines)
15° @ 1,500 RPM (Standard, L79 Engine); Max: 30° @ 5,100 RPM 17° @ 2,000 RPM (L36, L68 Engines); Max: 32° @ 5,000 RPM Max: 30° @ 3,800 RPM (L71 Engine) |
| Ignition Timing Vacuum Advance |
Begins: 6 inches Hg (Standard Engine)
Maximum: 15° @ 12 inches Hg Begins: 4 inches Hg (L79 Engine) Maximum: 16° @ 7 inches Hg Begins: 7 inches Hg (L36, L68 Engines) Maximum: 12° @ 12 inches Hg Begins: 8 inches Hg (L71 Engine) Maximum: 15° @ 15.5 inches Hg |
| Spark Plug |
AC44 (327 Cubic Inch Engines)
AC43N (427 Cubic Inch Engines) |
| Spark Plug Thread | 14 mm. |
| Spark Plug Torque | 25 lb.-ft. |
| Spark Plug Gap | .033 - .038 inch |
| Firing Order | 1-8-4-3-6-5-7-2 |
1967 Corvette Options
| RPO | Description | Production | Price |
| Genuine Leather Seats | 1,601 (6.98%) | $79.00 | |
| A01 | Soft Ray Tinted Glass, all windows | 11,331 (49.39%) | $15.80 |
| A02 | Soft Ray Tinted Glass, windshield | 6,558 (28.59%) | $10.55 |
| A31 | Power Windows | 4,036 (17.59%) | $57.95 |
| A82 | Headrests | 1,762 (7.68%) | $42.15 |
| A85 | Shoulder Belts | 1,426 (6.22%) | $26.35 |
| C07 | Auxiliary Hardtop (for convertible) | 6,880 (29.99%) | $231.75 |
| C08 | Vinyl Covering (for auxiliary hardtop) | 1,966 (8.57%) | $52.70 |
| C48 | Heater and Defroster Deletion (credit) | 35 (0.15%) | n/a |
| C60 | Air Conditioning | 3,788 (16.51%) | $412.90 |
| F41 | Special Front and Rear Suspension | 2,198 (9.58%) | $36.90 |
| G81 | Positraction Rear Axle, all ratios | 20,308 (88.53%) | $42.15 |
| J50 | Power Brakes | 4,766 (20.78%) | $42.15 |
| J56 | Special Heavy Duty Brakes | 267 (1.16%) | $342.30 |
| K19 | Air Injection Reactor | 2,573 (11.22%) | $44.75 |
| K66 | Transistor Ignition System | 5,759 (25.10%) | $73.75 |
| L36 | 427 cu. in. 390hp Engine | 3,832 (16.70%) | $200.15 |
| L68 | 427 cu. in. 400hp Engine | 2,101 (9.16%) | $305.50 |
| L71 | 427 cu. in. 435hp Engine | 3,754 (16.36%) | $437.10 |
| L79 | 327 cu. in. 350hp Engine | 6,375 (27.79%) | $105.35 |
| L88 | 427 cu. in. 430hp Engine | 20 (0.09%) | $957.90 |
| L89 | Aluminum Cynlinder Heads for L71 | 16 (0.07%) | $368.65 |
| M20 | 4-Speed Manual Transmission | 9,157 (39.92%) | $184.35 |
| M21 | 4-Speed Manual Transmission, close ratio | 11,015 (48.02%) | $184.35 |
| M22 | 4-Speed Manual Transmission, close ratio, heavy duty | 20 (0.09%) | $237.00 |
| M35 | Powerglide Automatic Transmission | 2,324 (10.13%) | $194.35 |
| N03 | 36 Gallon Fuel Tank (Coupe only) | 2 (0.01%) | $198.05 |
| N11 | Off Road Exhaust System | 2,326 (10.14%) | $36.90 |
| N14 | Side Mount Exhaust System | 4,209 (18.35%) | $131.65 |
| N36 | Telescopic Steering Column | 2,415 (10.53%) | $42.15 |
| N40 | Power Steering | 5,747 (25.05%) | $94.80 |
| N89 | Cast Aluminum Bolt-on Wheels (5) | 720 (3.14%) | $263.30 |
| P92 | Whitewall Tires, 7.75x15 | 13,445 (58.61%) | $31.35 |
| QB1 | Redline Tires, 7.75x15 | 4,230 (18.44%) | $46.65 |
| U15 | Speed Warning Indicator | 2,108 (9.19%) | $10.55 |
| U69 | AM-FM Radio | 22,193 (96.74%) | $172.75 |
|
Total Production:
22,940
Notes: Base Corvette Coupe with 327 cu. in. 300 hp engine and three speed manual transmission: $4,388.00. |
|||
Colors
| Code | Exterior | Quantity | Interior | Soft Top | Wheels |
| 900 | Tuxedo Black | 815 (3.55%) | Black / Red / Bright Blue | Black / White / Teal Blue | Silver |
| 972 | Ermine White | 1,423 (6.20%) | Black / Red / Bright Blue | Black / White / Teal Blue | Silver |
| 974 | Rally Red | 2,341 (10.20%) | Black / Red / White | Black / White / Teal Blue | Silver |
| 976 | Marina Blue | 3,840 (16.74%) | Black / Bright Blue / White | Black / White / Teal Blue | Silver |
| 977 | Lynndale Blue | 1,381 (6.02%) | Black / White / Teal Blue | Black / White / Teal Blue | Silver |
| 980 | Elkhart Blue | 1,096 (4.78%) | Black / Teal Blue | Black / White / Teal Blue | Silver |
| 983 | Goodwood Green | 4,293 (18.71%) | Black / Saddle / White / | Black / White / Teal Blue | Silver |
| 984 | Sunfire Yellow | 2,325 (10.14%) | Black / White | Black / White / Teal Blue | Silver |
| 986 | Silver Pearl | 1,952 (8.51%) | Black / Teal Blue | Black / White / Teal Blue | Silver |
| 988 | Marlboro Maroon | 3,464 (15.10%) | Black / White / Saddle | Black / White / Teal Blue | Silver |
