To learn more about the 1968 Corvette, click here.
1968 Corvette Specs
Body Specs |
|
| Wheelbase | 98.00 inches |
| Overhang (Front) | 40.2 inches |
| Overhang (Rear) | 43.9 inches |
| Front Track | 58.3 inches |
| Rear Track | 59.0 inches |
| Length (less bumpers) | 179.2 inches |
| Length | 182.1 inches |
| Front Fender Overall Width | 69.2 inches |
| Rear Fender Overall Width | 68.6 inches |
| Overall Height (Design, Coupe) | 47.8 inches |
| Front Bumper to Ground | 9.2 inches |
| Rear Bumper to Ground | 12.3 inches |
| Hood (at Rear) to Ground | 26.6 inches |
| Rocker Panel to Ground (Front) | 7.6 inches |
| Rocker Panel to Ground (Rear) | 7.6 inches |
| Bottom of Door to Ground (Closed) | 10.0 inches |
| Windshield Slope Angle | 53° |
| Body Zero to Ground (Front) | 7.6 inches |
| Body Zero to Ground (Rear) | 7.6 inches |
| Headlamp to Ground | 17.5 inches |
| Tail Lamp to Ground | 25.7 inches |
| Hood Length at Centerline | 54.4 inches |
| Body Upper Structure Length at Centerline | 54.7 inches (Coupe) |
| Front Bumper to Ground | 9.2 inches |
| Rear Bumper to Ground | 12.3 inches |
| Oil Pan to Ground | 4.8 inches |
| Front Suspension to Ground | 3.7 inches |
| Flywheel Housing to Ground | 5.2 inches |
| Exhaust System to Ground | 4.9 inches |
| Spare Tire Well to Ground | 5.1 inches |
| Minimum Running Ground Clearance | 4.9 inches |
| Head Room |
36.2 inches (Coupe)
37.1 inches (Convertible, Soft Top) 36.0 inches (Convertible, Hard Top) |
| Shoulder Room | 46.9 inches |
| Hip Room | 48.8 inches |
| Tire Size | F70-15-4PR |
| Recommended Tire Inflation | 24 PSI |
| Wheels, Regular Production | Size: 15 x 7.00 |
| Three Speed Transmission |
1st Gear 2.54:1
2nd Gear 1.50:1 3rd Gear 1.00:1 Reverse Gear 2.63:1 |
|
Turbo Hydra-Matic (Automatic) Transmission
(Not Available with L71 Engine) |
1st Gear 2.48:1
2nd Gear 1.48:1 3rd Gear 1.00:1 Reverse Gear 2.08:1 |
| Lubricant Capacity | 3 Quarts |
|
Four Speed M20 Transmission
(Not available with L71 Engine) |
1st Gear 2.52:1
2nd Gear 1.88:1 3rd Gear 1.47:1 4th Gear 1.00:1 Reverse Gear 2.59:1 |
|
Close Ratio Four Speed
M21 Transmission (Not available with Standard Engine) |
1st Gear 2.20:1
2nd Gear 1.64:1 3rd Gear 1.27:1 4th Gear 1.00:1 Reverse Gear 2.26:1 |
| Transmission Lubricant Type |
Military MIL-L-2105-B
SAE 80 |
| Lubricant Capacity |
Three Speed: 2 Quarts
Four Speed: 2.5 Quarts |
| Differential Lubricant Type |
Military MIL-L-2105-B
SAE 80 |
| Differential Lubricant Capacity | 3.7 pints |
| Axle Ratio |
Standard: 3.36:1
Turbo Hydra-Matic (Automatic): 2.73:1 Optional: 3.08:1 L36, L68, L79 Engines: 3.36:1, 3.55:1, 4.11:1 L71 Engine: 3.36:1, 3.55:1, 3.70:1, 4.11:1 |
| Transmission Synchromesh |
Three Speed: 2nd and 3rd Gears
Four Speed: All Four Gears |
| Standard Fuel Tank Capacity | 20 Gallons |
|
Steering Wheel Diameter
(Power, Manual Steering) |
16.0 inches |
| Steering Ratio | 16.0:1 |
| Wheel Turns | 3.4 |
|
|
| Model 19467 Convertible |
|
| Model 19437 Sport Coupe |
|
|
| |
|
|
|
| Three Speed Manual Transmission |
300 Horsepower Standard Engine: 3,510 lb.
Pounds / Horsepower: 11.70 |
| Four Speed Manual Transmission |
300 Horsepower Standard Engine: 3,504 lb.
Pounds / Horsepower: 11.68 |
| Four Speed Manual Transmission |
350 Horsepower L79 Engine: 3,516 lb.
Pounds / Horsepower: 10.05 |
| Four Speed Manual Transmission |
390 Horsepower L36 Engine: 3,682 lb.
Pounds / Horsepower: 9.44 |
| Four Speed Manual Transmission |
400 Horsepower L68 Engine: 3,686 lb.
Pounds / Horsepower: 9.21 |
| Four Speed Manual Transmission |
435 Hosepower L71 Engine: 3,653 lb.
Pounds / Horsepower: 8.40 |
|
Turbo Hydra-Matic
Automatic Transmission |
300 Horsepower Standard Engine: 3,573 lb.
Pounds / Horsepower: 11.91 |
|
Turbo Hydra-Matic
Automatic Transmission |
390 Horsepower L36 Engine: 3,751 lb.
Pounds / Horsepower: 9.62 |
|
Turbo Hydra-Matic
Automatic Transmission |
400 Horsepower L68 Engine: 3,755 lb.
Pounds / Horsepower: 9.38 |
|
|
|
| Power Windows (RPO A31) | +5 lb. |
| Auxiliary Top (RPO C07) | +48 lb. |
| Air Conditioning (RPO C60) | +95 lb. |
| Power Brakes (RPO J50) | +10 lb. |
| Heavy Duty Power Brakes (RPO J56) | +6 lb. |
|
427 cubic inch Engine
390 Horsepower (RPO L36) |
+178 lb. |
|
427 cubic inch Engine
400 Horsepower (RPO L68) |
+4 lb. |
|
427 cubic inch Engine
435 Horsepower (RPO L71) |
+149 lb. |
|
327 cubic inch Engine
350 Horsepower (RPO L79) |
+12 lb. |
| Aluminum Cylinder Heads (RPO L89) | -73 lb. |
| Four Speed Transmission (RPO M20) | -6 lb. |
| Turbo Hydra-Matic (Automatic) Transmission (RPO M40) | +63 lb. |
| Power Steering (RPO N40) | +21 lb. |
| Radio AM - FM Pushbutton (RPO U69) | +16 lb. |
| Radio Stereo Equipment (RPO U79) | +11 lb. |
| Power Brakes | +10 lb. |
|
|
| Type: | V8 |
| Valve Location: | In Head |
| Bore / Stroke: |
4.00" / 3.25" (Standard, L79 327 Cubic Inch)
4.25" / 3.76" (L36, L72 427 Cubic Inch) |
| Displacement: |
Standard, L79: 327 Cubic Inches
L36, L68, L71: 427 Cubic Inches |
| Compression Ratio: |
10.0:1 (Standard Engine)
10.25:1 (L36, L68 Engines) 11.0:1 (L71, L79 Engines) |
| Rocker Arms | Stamping, Steel |
| Rocker Arm Ratio | 1.5:1 |
|
Valve Train Lash, Inlet / Exhaust
Hydraulic Lifters |
Zero |
|
Valve Train Lash, Inlet / Exhaust
Mechanical Lifters (RPO L72) |
Inlet: .024 inch
Exhaust: .028 inch |
| Crankshaft Material: | Forged Steel |
| Camshaft Material: | Cast Alloy Iron |
| Oil Pump Type: | Gear |
| Normal Oil Pressure |
30 - 45 psi @ 1,500 RPM
50 - 75 psi @ 2,000 RPM |
| Oil Pressure Gauge | Mechanical |
| Crankcase Oil Capacity, Standard, L79 Engines |
4 Quarts, Less Filter
5 Quarts, With Filter |
| Crankcase Oil Capacity, L36, L68, L71, L88 and L89 Engines |
5 Quarts, Less Filter
6 Quarts, With Filter |
| Recommended Oil Grade |
Above 32°: SAE 20W, SAE 10W-30
To 0°: SAE 10W or SAE 10W-30 Below 0°: SAE 5W or SAE 5W-20 |
| Fuel Filter | Strainer |
| Fuel Pump | Mechanical |
| Fuel Pressure | 5¼ - 6½ PSI |
| Cooling System Capacity |
327 cubic inch Engines
16 Quarts (with heater) 15 Quarts (without heater) 427 cubic inch Engines 23 Quarts (with heater) 22 Quarts (without heater) |
| Thermostat Type | Choke |
| Radiator Cap Relief Pressure | 15 +/- 1 PSI |
| Battery |
12 volt
61 Amp hr. @ 20 hr. 6 cells / 66 Plates |
| Thermostat Opening | 192° - 198° F |
|
Brakes |
|
| Type | Caliper Disc, Four Wheel Hydraulic |
| Effective Area | 78.1 Square Inches |
| Swept Area | 461.2 Square Inches |
| Disc | Vented |
| Pistons per Caliper | Four |
|
Horsepower |
|
| Standard Engine (327 cubic inch) |
300 hp @ 5,000 RPM;
Torque: 360 lb-ft @ 3,400 RPM |
| RPO L79 (327 cubic inch) |
350 hp @ 5,800 RPM;
Torque: 360 lb-ft. @ 3,600 RPM |
| RPO L36 (427 cubic inch) |
390 hp @ 5,200 RPM;
Torque: 460 lb-ft @ 3,600 RPM |
| RPO L68 (427 cubic inch) |
400 hp @ 5,400 RPM;
Torque: 460 lb-ft @ 3,600 RPM |
| RPO L71 (427 cubic inch) |
435 hp @ 5,800 RPM;
Torque: 460 lb-ft @ 4,000 RPM |
|
Ignition System |
|
| Coil | Delco-Remy 1115202 Base, L79; 1115264 L36, L68; 1111141 L36; 1115210 L71 |
| Coil current rating |
4 amps (engine stopped)
1.8 amps (engine running) |
| Breaker Gap | .019" (New) |
|
Ignition Timing
Initial Design Setting |
6° @ 500 RPM (Standard Engine)
10° @ 700 RPM (L79 Engine) 4° @ 550 RPM (L36, L68 Engines) 4° @ 750 RPM (L71 Engine) |
| Ignition Timing Centrifugal Advance |
Begins: 900 RPM (Standard, 427 Engines)
950 RPM (L79 Engine) 15° @ 1,500 RPM (Standard); 20°: @ 1,800 RPM (L79 Engine) 17° @ 2,000 RPM (L36, L68 Engines); Max: 30° @ 5,100 RPM (Standard Engine); Max: 30° @ 4,700 RPM (L79 Engine); Max: 32° @ 5,000 RPM (L36, L68 Engines) Max: 30° @ 3,800 RPM (L71 Engine) |
| Ignition Timing Vacuum Advance |
Begins: 6 inches Hg (Standard Engine)
Maximum: 15° @ 12 inches Hg Begins: 6 inches Hg (L79 Engine) Maximum: 15° @ 15.5 inches Hg Begins: 7 inches Hg (L36, L68 Engines) Maximum: 12° @ 12 inches Hg Begins: 8 inches Hg (L71 Engine) Maximum: 15° @ 15.5 inches Hg |
| Spark Plug |
AC44 (327 Cubic Inch Engines)
AC43N (427 Cubic Inch Engines) |
| Spark Plug Thread | 14 mm. |
| Spark Plug Torque | 25 lb.-ft. |
| Spark Plug Gap | .033 - .038 inch |
| Firing Order | 1-8-4-3-6-5-7-2 |
1968 Corvette Options
| RPO | Description | Production | Price |
| Genuine Leather | 2,429 (8.50%) | $79.00 | |
| A01 | Soft Ray Tinted Glass, all windows | 17,635 (61.73%) | $15.80 |
| A02 | Soft Ray Tinted Glass, windshield | 5,509 (19.29%) | $10.55 |
| A31 | Power Windows | 7,065 (24.73%) | $57.95 |
| A82 | Headrests | 3,197 (11.19%) | $42.15 |
| A85* | Custom Shoulder Belts | 350 (1.23%) | $26.35 |
| C07 | Auxiliary Hardtop (for convertible) | 8,735 (30.58%) | $231.75 |
| C08 | Vinyl Covering (for auxiliary hardtop) | 3,050 (10.68%) | $52.70 |
| C50 | Rear Window Defroster | 693 (2.43%) | $31.60 |
| C60 | Air Conditioning | 5,664 (19.83%) | $412.90 |
| F41 | Special Front and Rear Suspension | 1,758 (6.15%) | $36.90 |
| G81 | Positraction Rear Axle, all ratios | 27,008 (94.55%) | $46.35 |
| J50 | Power Brakes | 9,559 (33.46%) | $42.15 |
| J56 | Special Heavy Duty Brakes | 81 (0.28%) | $384.45 |
| K66 | Transistor Ignition System | 5,457 (19.10%) | $73.75 |
| L36 | 427 cu. in. 390hp Engine | 7,717 (27.01%) | $200.15 |
| L68 | 427 cu. in. 400hp Engine | 1,932 (6.76%) | $305.50 |
| L71 | 427 cu. in. 435hp Engine | 2,898 (10.14%) | $437.10 |
| L79 | 327 cu. in. 350hp Engine | 9,440 (33.05%) | $105.35 |
| L88 | 427 cu. in. 430hp Engine | 80 (0.28%) | $947.90 |
| L89 | Aluminum Cynlinder Heads for L71 | 624 (2.18%) | $805.75 |
| M20 | 4-Speed Manual Transmission | 10,760 (37.67%) | $184.35 |
| M21 | 4-Speed Manual Transmission, close ratio | 12,337 (43.19%) | $184.35 |
| M22 | 4-Speed Manual Transmission, close ratio, heavy duty | 80 (0.28%) | $263.30 |
| M40 | Turbo Hydra-Matic Automatic Transmission | 5,063 (17.72%) | $226.45 |
| N11 | Off Road Exhaust System | 4,695 (16.44%) | $36.90 |
| N36 | Telescopic Steering Column | 6,477 (22.67%) | $42.15 |
| N40 | Power Steering | 12,364 (43.28%) | $94.80 |
| P01 | Bright Metal Wheel Cover | 8,971 (31.40%) | $57.95 |
| PT6 | Red Stripe Tires, F70x15, nylon | 11,686 (40.91%) | $31.30 |
| PT7 | White Stripe Tires, F70x15, nylon | 9,692 (33.93%) | $31.30 |
| U15 | Speed Warning Indicator | 3,453 (12.09%) | $10.55 |
| U69 | AM-FM Radio | 24,609 (86.15%) | $172.75 |
| U79 | AM-FM Radio, stereo | 3,311 (11.59%) | $278.10 |
| UA6 | Alarm System | 388 (1.36%) | $26.35 |
|
Total Production:
28,566
Notes: Base Corvette Coupe with 327 cu. in. 300 hp engine and three speed manual transmission: $4,663.00. |
|||
Colors
| Code | Exterior | Quantity | Interior | Soft Top | Wheels |
| 900 | Tuxedo Black | 708 (2.48%) | Black / Dark Blue / Dark Orange / Gunmetal / Medium Blue / Red / Tobacco | Black / White / Beige | Silver |
| 972 | Polar White | 1,868 (6.54%) | Black / Dark Blue / Dark Orange / Gunmetal / Medium Blue / Red / Tobacco | Black / White / Beige | Silver |
| 974 | Rally Red | 2,918 (10.21%) | Black / Red | Black / White / Beige | Silver |
| 976 | LeMans Blue | 4,722 (16.53%) | Black / Medium Blue / Dark Blue | Black / White / Beige | Silver |
| 978 | International Blue | 2,473 (8.66%) | Black / Medium Blue / Dark Blue | Black / White / Beige | Silver |
| 983 | British Green | 4,779 (16.73%) | Black | Black / White / Beige | Silver |
| 984 | Safari Yellow | 3,133 (10.97%) | Black | Black / White / Beige | Silver |
| 986 | Silverstone Silver | 3,435 (12.02%) | Black / Dark Blue / Gunmetal | Black / White / Beige | Silver |
| 988 | Cordovan Maroon | 1,155 (4.04%) | Black | Black / White / Beige | Silver |
| 992 | Corvette Bronze | 3,374 (11.81%) | Black / Dark Orange / Tobacco | Black / White / Beige | Silver |
