To learn more about the 1981 Corvette, click here.
1981 Corvette Specs
Body Specs |
|
| Wheelbase | 98.0 inches |
| Overhang (Front) | 42.4 inches |
| Overhang (Rear) | 44.9 inches |
| Front Track | 58.7 inches |
| Rear Track | 59.5 inches |
| Length | 185.3 inches |
|
Ground Clearance
Differential to Ground |
12.9 inches |
|
Ground Clearance
Front Bumper to Ground |
9.4 inches |
|
Ground Clearance
Rear Bumper to Ground |
11.4 inches |
|
Ground Clearance
Rear Axle to Ground |
12.9 inches |
| Minimum Ground Clearance |
4.1 inches
(Measured at Catalytic Converter) |
Overall Height | 48.1 inches |
| Rocker Panel to Ground (Front) | 8.0 inches |
| Rocker Panel to Ground (Rear) | 7.7 inches |
| Luggage Capacity | 8.4 Cubic Feet |
| Cowl Height | 35.4 inches |
| Windshield Slope Angle | 57.0° |
| Effective Head Room | 36.2 inches |
| Shoulder Room | 47.5 inches |
| Hip Room | 49.9 inches |
| Tire Size | P225/70R15 |
| Recommended Tire Inflation | 35 PSI Front; 35 PSI Rear |
| Wheels, Regular Production | Size: 15 x 8 |
| Synchronization | All Forward Gears |
| Turbo Hydra-Matic (Automatic) Transmission |
1st Gear 2.52:1
2nd Gear 1.52:1 3rd Gear 1.00:1 Reverse Gear 1.93:1 |
| Four Speed Transmission |
1st Gear 2.88:1
2nd Gear 1.91:1 3rd Gear 1.33:1 4th Gear 1.00:1 Reverse Gear 2.78:1 |
| Transmission Lubricant Type |
GL-5 Gear Lubricant
80W or 80W-90 |
| Lubricant Capacity | Four Speed Manual: 3.4 Quarts |
| Differential Lubricant Type |
GL-5
SAE 80W-90 |
| Axle Ratio |
Automatic, Four Speed Manual
2.72:1, 2.87:1 |
| Transmission Synchromesh | All Four Gears |
| Standard Fuel Tank Capacity | 24 Gallons (Approximately) |
| Steering Ratio | 16.1:1 |
| Steering Wheel Diameter | 14.5 inches |
| Wheel Turns | 2.58 |
| Turning Diameters |
40.4 feet (Curb to Curb)
41.3 feet (Wall to Wall) |
|
|
| 49 State |
15 mpg (Automatic)
14 mpg (Manual) |
| California |
15 mpg (Automatic)
14 mpg (Manual) |
|
|
| Model 1YY87 Sport Coupe |
(Curb)
(Shipping) |
|
Curb Weight: The calculated weight of a vehicle with standard equipment, only as designed with the additional load of oils, lubes coolants and fuel all filled to capacity.
Shipping Weight: Same as base curb weight except 3 gallons of gasoline. |
|
|
|
|
|
|
|
|
Standard Engine
With Turbo Hydra Matic Transmission |
+38.2 lb.
(+22.4 lb. Front; +15.8 lb. Rear) |
|
Radio, AM/FM Stereophonic
(RPO U58) |
+10 lb.
(+6 lb. Front; +4 lb. Rear) |
|
Radio, AM/FM Stereo With CB,
8 Track Tape Player (RPO UM5) |
+1.2 lb.
(+.8 lb. Front; +.4 lb. Rear) |
|
Radio, AM/FM Stereophonic
With Cassette Tape Player (RPO UM6) |
+1.2 lb.
(+.8 lb. Front; +.4 lb. Rear) |
|
Radio, AM/FM Stereophonic
With 8 Track Tape Player (RPO UM4) |
+2.8 lb.
(+1.4 lb. Front; +1.4 lb. Rear) |
|
Radio, AM/FM Stereophonic
With CB, Cassette Tape Player (RPO UN5) |
+1.2 lb.
(+.8 lb. Front; +.4 lb. Rear) |
|
Gymkhana Suspension
(RPO FE7) |
+37.0 lb.
(+5.2 lb. Front; +31.8 lb. Rear) |
|
Power Antenna
All Radios Except Citizen's Band (RPO U75) |
+3.6 lb.
(-0.8 lb. Front; +4.4 lb. Rear) |
|
Aluminum Wheels
(RPO N90) |
-47.1 lb.
(-23.8 lb. Front; -23.3 lb. Rear) |
|
Glass Roof Panels
(RPO CC1) |
+14.6 lb.
(+4.4 lb. Front; +10.2 lb. Rear) |
|
Carrier-Roof Panel
(RPO K30) |
+7.0 lb.
(-1.8 lb. Front; +8.8 lb. Rear) |
|
|
| Type: | V8 |
| Valve Location: | In Head |
| Bore / Stroke: | 4.00" / 3.48" |
| Displacement: |
350 Cubic Inches
(5.7 Liters) |
| Compression Ratio: | 8.2:1 |
| Cylinder Head Material: | High Chrome Cast Alloy Iron |
| Cylinder Block Material: | Cast Alloy Iron |
| Oil Pump Type: | Gear |
| Crankcase Oil Capacity | 4.0 Quarts, Less Filter |
| Recommended Oil Grade |
Above 20°F: SAE 20W-20, SAE 10W-30, 10W-40
20W-40, 20W-50 0°F to 60°F: SAE 10W, 5W-30, 10W-30, 10W-40 Below 20°F: SAE 5W-20, 5W-30 |
| Fuel Filter |
Mesh Strainer in Gasoline Tank and
Paper Filter Element in Carburetor Inlet. |
| Fuel Pump | Mechanical |
| Fuel Pressure | 7.5 - 9.0 PSI |
| Cooling System Capacity | 21.6 Quarts |
| Radiator Cap Relief Pressure | 15 PSI |
| Battery | 12 volt - 115 Minute Reserve Capacity |
|
Brakes |
|
| Type | Caliper Disc, Four Wheel Hydraulic |
| Gross Lining Area | 86.30 Square Inches |
| Swept Area | 498.30 Square Inches |
| Disc | Vented |
|
Horsepower |
|
| Standard Engine (350 cubic inch) |
190 hp @ 4,200 RPM;
Torque: 280 lb-ft @ 1,600 RPM |
|
Ignition System |
|
| Ignition Timing Centrifugal Advance | Does Not Apply |
| Ignition Timing Vacuum Advance | Does Not Apply |
| Initial Timing |
Distributor | 1103443 | Base Engine
6° BTC Manual / Automatic |
| Spark Plug | R45TS |
| Spark Plug Thread | 14 mm. |
| Spark Plug Gap | .045 inch |
| Firing Order | 1-8-4-3-6-5-7-2 |
| Idle |
Standard Engine, Manual Transmission:
700 RPM (In Neutral) Standard Engine, Automatic Transmission: 500 RPM (In Drive) |
1981 Corvette Options
| RPO | Description | Production | Price |
| A42 | Power Driver Seat | 29,200 (71.91%) | $183.00 |
| AU3 | Power Door Locks | 36,322 (89.45%) | $145.00 |
| C49 | Rear Window Defogger | 36,893 (90.86%) | $119.00 |
| CC1 | Removable Glass Roof Panels | 29,095 (71.65%) | $414.00 |
| D84 | Two-Tone Paint | 5,352 (13.18%) | $399.00 |
| DG7 | Electric Sport Mirrors | 13,567 (33.41%) | $117.00 |
| F51 | Heavy Duty Shock Absorbers | 1,128 (2.78%) | $37.00 |
| FE7 | Gymkhana Suspension | 7,803 (19.22%) | $57.00 |
| G92 | Performance Axle Ratio | 2,400 (5.91%) | $20.00 |
| K35 | Cruise Control | 32,522 (80.09%) | $155.00 |
| MM4 | 4-Speed Manual Transmission | 5,757 (14.18%) | n/a |
| N90 | Aluminum Wheels (4) | 36,485 (89.85%) | $428.00 |
| QGR | White Letter SBR Tires, P225 / 70R15 | 21,939 (54.03%) | $72.00 |
| QXH | White Letter SBR Tires, P255 / 60R15 | 18,004 (44.34%) | $491.92 |
| U58 | AM-FM Radio, stereo | 5,145 (12.67%) | $95.00 |
| U75 | Power Antenna | 32,903 (81.03%) | $55.00 |
| UL5 | Radio Delete | 315 (0.78%) | n/a |
| UM4 | AM-FM Radio, etc stereo with 8-track | 8,262 (20.35%) | $386.00 |
| UM5 | AM-FM Radio, etc stereo with 8-track/CB | 792 (1.95%) | $712.00 |
| UM6 | AM-FM Radio, etc stereo with cassette | 22,892 (56.38%) | $423.00 |
| UN5 | AM-FM Radio, etc stereo with cassette/CB | 2,349 (5.78%) | $750.00 |
| V54 | Roof Panel Carrier | 3,303 (8.13%) | $135.00 |
| YF5 | California Emission Certification | 4,951 (12.19%) | $46.00 |
| ZN1 | Trailer Package | 916 (2.26%) | $110.00 |
|
Total Production:
40,606
Notes: Base Corvette Coupe with 350 cu. in. 190 hp engine: $16,258.52. |
|||
Colors
| Code | Exterior | Quantity | Interior | ||
| 06 | Mahogany Metallic | 1,092 (2.69%) | Camel / Dark Red | ||
| 10 | White | 6,387 (15.73%) | Black / Charcoal / Camel / Dark Blue / Dark Red / Medium Red / Silver Grey | ||
| 13 | Silver Metallic | 2,590 (6.38%) | Black / Charcoal / Dark Blue / Medium Red / Silver Grey | ||
| 19 | Black | 4,712 (11.60%) | Black / Charcoal / Camel / Dark Red / Medium Red / Silver Grey | ||
| 24 | Bright Blue Metallic | 1 (0.00%) | Charcoal / Camel / Dark Blue / Silver Grey | ||
| 28 | Dark Blue Metallic | 2,522 (6.21%) | Camel / Dark Blue / Medium Red / Silver Grey | ||
| 33 | Silver Metallic | 3,369 (8.30%) | Charcoal / Dark Blue / Dark Red / Silver Grey | ||
| 33/38 | Silver / Dark Blue | n/a | Dark Blue / Silver Gray | ||
| 33/39 | Silver / Charcoal | n/a | Charcoal / Silver Gray | ||
| 38 | Dark Blue Metallic | 496 (1.22%) | Camel / Dark Blue / Silver Grey | ||
| 39 | Charcoal Metallic | 613 (1.51%) | Charcoal / Dark Red / Silver Grey | ||
| 50 | Beige | 2,239 (5.51%) | Charcoal / Camel / Dark Blue / Dark Red | ||
| 50/74 | Beige / Dark Bronze | n/a | Camel | ||
| 52 | Yellow | 1,031 (2.54%) | Black / Charcoal / Camel | ||
| 59 | Beige | 3,842 (9.46%) | Camel / Dark Blue / Dark | ||
| 74 | Dark Bronze | 432 (1.06%) | Charcoal / Camel | ||
| 75 | Red | 4,310 (10.61%) | Black / Charcoal / Camel / Medium Red / Silver Grey | ||
| 79 | Maroon Metallic | 1,618 (3.98%) | Black / Charcoal / Camel / Medium Red / Silver Grey | ||
| 80 | Autumn Red | 1,505 (3.71%) | Charcoal / Camel / Dark Red / Silver Grey | ||
| 80/98 | Autumn Red / Dark Claret | n/a | Dark Red / Silver Gray | ||
| 84 | Charcoal Metallic | 3,485 (8.58%) | Black / Charcoal / Camel / Medium Red / Silver Grey | ||
| 98 | Dark Claret Metallic | n/a | Camel / Dark Red / Silver | ||
|
Notes: The vast color choices was due to the fact that 1981 Corvettes were built at both the St. Louis MO and Bowling Green KY plants. |
|||||
