To learn more about the 1994 Corvette, click here.
1994 Corvette Specs
Body Specs |
|
| Wheelbase | 96.2 inches |
| Overhang (Front) | 41.6 inches |
| Overhang (Rear) | 40.7 inches |
| Front Track | 57.7 inches |
| Rear Track |
59.1 inches
ZR-1: 60.6 inches |
| Length |
178.5 inches
ZR-1: 178.5 inches |
| Width |
70.7 inches
ZR-1: 73.1 inches |
|
Ground Clearance
Differential to Ground |
7.0 inches |
|
Ground Clearance
Front Bumper to Ground |
5.1 inches |
|
Ground Clearance
Rear Bumper to Ground |
9.2 inches |
| Minimum Ground Clearance |
ZR-1, Coupe: 4.2 inches / Convertible: 3.6 inches
(Measured at Catalytic Converter) |
| Overall Height |
46.3 inches (Coupe)
47.3 inches (Convertible) |
| Rocker Panel to Ground (Front) | 6.9 inches |
| Rocker Panel to Ground (Rear) | 6.8 inches |
| Cargo Capacity |
100 lbs. (Coupe, Convertible)
6.6 cubic feet (Convertible) 12.6 cubic feet (Coupe, ZR-1) Liftover Height: 35.4 Inches (Coupe) |
| Cowl Height | 33.1 inches |
| Effective Head Room |
Coupe: 36.5 inches
Convertible: 37.0 inches |
| Shoulder Room | 53.9 inches |
| Hip Room | 49.3 inches |
| Tire Size |
Coupe / Convertible
P255/45ZR17 (Front) P285/40ZR17 (Rear) (Goodyear Eagle GS-C Steel Belted Directional, Asymmetrical) ZR-1 P275/40ZR17 (Front) P315/35ZR17 (Rear) |
| Wheel Size |
Coupe / Convertible
17" x 8.5" (Front) 17" x 9.5" (Rear) ZR-1 17" x 9.5" (Front) 17" x 11.0" (Rear) |
| Recommended Tire Inflation |
Coupe: 35 PSI Front / Rear
Convertible: 30 PSI Front / Rear |
| Manual Six Speed Transmission |
Coupe / Convertible / ZR-1
1st Gear 2.68:1 2nd Gear 1.80:1 3rd Gear 1.31:1 4th Gear 1.00:1 5th Gear .75:1 6th Gear .50:1 Reverse Gear 2.50:1 |
| Turbo Hydra-Matic (Automatic) Transmission |
1st Gear 3.06:1
2nd Gear 1.63:1 3rd Gear 1.00:1 4th Gear 0.70:1 Reverse Gear 2.29:1 |
|
Turbo Hydra-Matic (Automatic)
Transmission Lubricant |
Dextron IIE
8.0 Pints |
| Maximum Upshift Speed |
1 > 2: 49 MPH
2 > 3: 93 MPH 3 > 4: N/A |
|
Manual Transmission
Lubricant Type |
5W-30 Texaco
.987 Pints |
| Axle Ratio |
(Manual Transmission)
3.45:1, 3.33:1 (Automatic Transmission) 2.59:1, 3.07:1 |
| Standard Fuel Tank Capacity | 20 Gallons |
| EPA Fuel Economy |
LT1 Engine / Manual Transmission
15 MPG (City) / 23 MPG (Highway) 18 MPG (Combined) LT1 Engine / Automatic Transmission 15 MPG (City) / 22 MPG (Highway) 18 MPG (Combined) ZR-1 LT5 Engine 15 MPG (City) / 24 MPG (Highway) 18 MPG (Combined) |
| Steering Ratio | 15.7:1 |
| Steering Turns, Lock to Lock | 2.32 |
|
Turning Diameters
Outside Front |
41.3 feet (Wall to Wall)
40.0 feet (Curb to Curb) |
| Steering Wheel Diameter | 15.0 inches |
|
|
| Manual |
City: 15
Highway: 23 Combined: 18 |
| Automatic |
City: 15
Highway: 22 Combined: 18 |
| Manual |
City: 15
Highway: 24 Combined: 18 |
|
|
| Model 1YY07 2-Door Hatchback Coupe |
Curb Mass
|
| Model 1YY67 2-Door Convertible |
Curb Mass
|
| Model 1YZ07 2-Door Hatchback Coupe (ZR1) |
Curb Mass
|
|
Reference - SAE J1100 Motor Vehicle Dimensions, Curb Weight Definition.
* Equivalent Test Weight Class - basis for US Environmental Protection Agency emission certifications. |
|
|
|
|
|
|
|
|
Removeble Plastic Roof Panel
(RPO CC3) |
-4.4 lb.
(-1.3 lb. Front; -3.1 lb. Rear) |
|
Electric Defogger System
Rear Window and Side Mirror (RPO Z6A) |
+0.8 lb.
(+0.4 lb. Front; +0.4 lb. Rear) |
|
Delco-Bose
Premium Audio System (RPO UU8) |
+8.3 lb.
(+3.0 lb. Front; +5.3 lb. Rear) |
|
Custom Adjustable Seats
(RPO AQ9) |
+10.5 lb.
(+3.0 lb. Front; +7.5 lb. Rear) |
|
Automatic Air Conditioning
(RPO C68) |
+2.2 lb.
+2.2 lb. Front |
|
Manual Transmission
(RPO ML9) |
-43.2 lb.
-23.8 lb. Front; -19.4 lb. Rear) |
|
Leather Seat Trim
(RPO AR9) |
+3.5 lb.
(+1.3 lb. Front; +2.2 lb. Rear) |
|
Adjustable Suspension Package
(RPO Z07) |
+24.2 lb.
(+18.4 lb. Front; +5.8 lb. Rear) |
|
|
| Type: | 90° V8 (LT5: DOHC 32-Valve) |
| Bore / Stroke: |
LT-1: 4.00" / 3.48"
LT-5: 3.90" x 3.66" |
| Engine Weight: |
LT1: 576.4 lbs. (Automatic)
635.6 lbs. (Manual) ZR-1 LT5: 753.6 lbs. |
| Fuel Requirement: |
91-Octane Rating
(LT1, ZR-1 Engines) |
| Compression Ratio: |
LT1: 10.5:1
LT5 (ZR-1): 11.0:1 |
| Cylinder Head Material: | Aluminum |
| Cylinder Block Material: |
LT1: Cast Iron
LT5 (ZR-1): Cast Aluminum |
| Oil Pump Type: | Gear |
| Cooling System Capacity |
9.39 Quarts (Manual Transmission)
9.61 Quarts (Automatic Transmission) 14.73 Quarts (ZR-1) |
| Radiator Cap Relief Pressure |
LT1: 15.0 PSI
LT5: 15.0 PSI |
| Battery |
LT1: 12 volt - 525 Amps Cold Cranking 0° (CCA)
LT5: 12 volt - 690 Amps Cold Cranking 0° (CCA) 54 Amp-hours |
| Alternator |
Delco-Remy
50 / 124 Amps (Idle / Max RPM) |
|
Fuel System |
|
| Type |
Sequential Fuel Injection
(LT1 and LT5 Engines) |
| Fuel Pump | Electric - In Fuel Tank |
| Point of Injection | Fuel Injectors at Inlet Ports |
| Flow | Pulse |
|
Horsepower |
|
| ZR-1 Engine LT5 (350 cubic inch) |
405 hp @ 5,800 RPM;
Torque: 385 lb-ft @ 5,200 RPM |
| Standard Engine LT1 (350 cubic inch) |
Manual Transmission: 300 hp @ 5,000 RPM;
Torque: 340 lb-ft @ 3,600 RPM |
|
Ignition System |
|
|
Spark Plug
(Standard LT1 Engine) |
R45LTSP
Make: AC |
|
Spark Plug
(ZR-1 LT5 Engine) |
FR2LS
Make: AC |
| Spark Plug Thread |
M14 x 1.25
ZR-1, LT5: N/A |
| Spark Plug Gap |
.050 inch
ZR-1, LT5: N/A |
| Spark Plug Tightening Torque |
18 - 22 lb. - ft.
ZR-1, LT5: N/A |
|
Brakes |
|
| Type | Hydraulic Power Brake Front and Rear Disc |
| Effective Area |
32.4 Square Inches (209 Square cm.) (Front)
18.4 Square Inches (119 Square cm.) (Rear) |
| Gross Lining Area |
33.0 Square Inches (213 Square cm.) (Front)
18.4 Square Inches (119 Square cm.) (Rear) |
| Swept Area |
111.9 Square Inches (722 Square cm.) (Front)
91.3 Square Inches (589 Square cm.) (Rear) |
| Rotor |
Outer Working Diameter: (302 mm.) 9.9 inches
Inner Working Diameter: 7.3 Inches (222 mm.) (Front), 7.6 Inches (232 mm.) (Rear) Type and Material: Vented, Gray Iron Vented (Front) HCE Iron Vented (Rear) |
1994 Corvette Options
| RPO | Description | Production | Price |
| 24S | Removable Roof Panel, blue tint (coupe) | 7,064 (30.28%) | $650.00 |
| 64S | Removable Roof Panel, bronze tint (coupe) | 3,979 (17.06%) | $650.00 |
| AC1 | Power Passenger Seat | 17,863 (76.57%) | $305.00 |
| AC3 | Power Driver Seat | 21,592 (92.55%) | $305.00 |
| AQ9 | Sport Seats | 9,023 (38.68%) | $625.00 |
| C2L | Dual Removable Roof Panels (coupe) | 3,875 (16.61%) | $950.00 |
| CC2 | Auxiliary Hardtop (convertible) | 682 (2.92%) | $1,995.00 |
| FX3 | Selective Ride and Handling, electronic | 4,570 (19.59%) | $1,695.00 |
| G92 | Performance Axle Ratio | 9,019 (38.66%) | $50.00 |
| MN6 | 6-Speed Manual Transmission | 6,012 (25.77%) | n/a |
| NG1 | New York Emission Requirements | 1,363 (5.84%) | $100.00 |
| PEG1 | Preferred Equipment Group 1 Included electronic A/C, Delco-Bose Stereo w/cassette and RPO AC3 | n/a | $1,333.00 |
| U1F | Stereo System with CD, Delco-Bose | 17,579 (75.35%) | $396.00 |
| UJ6 | Low Tire Pressure Warning Indicator | 5,097 (21.85%) | $325.00 |
| WY5 | Tires, Extended Mobility | 2,781 (11.92%) | $70.00 |
| YF5 | California Emission Requirements | 2,372 (10.17%) | $100.00 |
| Z07 | Adjustable Suspension Package (coupe) | 887 (3.80%) | $2,045.00 |
| ZR1 | Special Performance Package (coupe) | 448 (1.92%) | $31,258.00 |
|
Total Production:
23,330
Notes: Base Corvette Coupe with 350 cu. in. 300 hp engine and four speed automatic transmission: $36,185.00. |
|||
Colors
| Code | Exterior | Quantity | Interior | Soft Top | |
| 10 | Arctic White | 4,066 (17.43%) | Black / Light Beige / Light Gray / Red | Beige / Black / White | |
| 28 | Admiral Blue | 1,584 (6.79%) | Black / Light Beige / Light Gray | Beige / Black / White | |
| 41 | Black | 4,136 (17.73%) | Black / Light Beige / Light Gray / Red | Beige / Black / White | |
| 43 | Bright Aqua Metallic | 1,209 (5.18%) | Black / Light Beige / Light Gray | Beige / Black / White | |
| 45 | Polo Green Metallic | 3,534 (15.15%) | Black / Light Beige | Beige / Black | |
| 53 | Competition Yellow | 834 (3.57%) | Black / Light Beige / Light Gray | Beige / Black / White | |
| 66 | Copper Metallic | 116 (0.50%) | Black / Light Beige / Light Gray | Beige / Black / White | |
| 70 | Torch Red | 5,073 (21.74%) | Black / Light Beige / Light Gray / Red | Beige / Black / White | |
| 73 | Black Rose Metallic | 1,267 (5.43%) | Black / Light Beige / Light Gray | Beige / Black / White | |
| 75 | Dark Red Metallic | 1,511 (6.48%) | Black / Light Beige / Light Gray | Beige / Black / White | |
