To learn more about the 2012 Corvette, click here.
2012 Corvette Specs
Body Specs |
|||||
|
Wheelbase - Coupe, Convertible,
Z06, ZR1, Grand Sport: |
105.7 inches / 2,685 mm | ||||
| Length - Coupe, Convertible: | 174.60 inches / 4,435 mm | ||||
| Length - Z06, Grand Sport: | 175.60 inches / 4,460 mm | ||||
| Length - ZR1: | 176.20 inches / 4,476 mm | ||||
| Width, not including mirrors - Coupe, Convertible: | 72.60 inches / 1,844 mm | ||||
| Width, not including mirrors - Z06, ZR1, Grand Sport: | 75.90 inches / 1,928 mm | ||||
| Height - Coupe, Convertible, Z06, ZR1, Grand Sport: | 49.00 inches / 1,245 mm | ||||
| Front Track: | 62.10 inches / 1,677mm | ||||
| Rear Track: | 60.70 inches / 1,542 mm | ||||
| Min. Ground Clearance: | 3.7 inches | ||||
| Head Room, Coupe, Z06, ZR1, Grand Sport: | 38 inches / 962.0 mm | ||||
| Shoulder Room: | 55 inches / 1,397 mm | ||||
| Hip Room: | 54 inches / 1,371 mm | ||||
| Leg Room: | 43 inches / 1,092 mm | ||||
| Cargo Capacity: |
22 Cubic Feet / 634 Liters (Coupe, Z06)
11 Cubic Feet / 295 Liters (Convertible, top up) 5 Cubic Feet / 144 Liters (Convertible, top down) |
||||
| Tire Size: |
P245/40ZR-18 (Front)
P285/35ZR-19 (Rear) (Goodyear Eagle F1 GS, Extended Mobility) |
||||
| Tire Size, Z51 Sport Package: |
P245/40ZR-18 (Front)
P285/35ZR-19 (Rear) |
||||
| Tire Size, Z06, Grand Sport: |
P275/35ZR-18 (Front)
P325/30ZR-19 (Rear) |
||||
| Tire Size, ZR1: |
P285/30ZR-19 (Front)
P335/25ZR-20 (Rear) (Michelin Pilot Sport 2) |
||||
| Wheel Size - Coupe, Convertible: |
18 inch x 8.5 inch (Front)
19 inch x 10 inch (Rear) |
||||
| Wheel Size - Z06, Grand Sport: |
18 inch x 9.5 inch (Front)
19 inch x 12 inch (Rear) |
||||
| Wheel Type: | Cast Aluminum, Front and Rear | ||||
| Recommended Tire Inflation: | 30 PSI Front / Rear | ||||
| Manual Six Speed Transmission: |
1st Gear 2.66:1
2nd Gear 1.78:1 3rd Gear 1.30:1 4th Gear 1.00:1 5th Gear .74:1 6th Gear .50:1 Reverse Gear 2.90:1 Final Drive Ration 3.42 |
||||
| Tremec T56 Manual Six Speed Transmission - Z51 Sport Package: |
1st Gear 2.97:1
2nd Gear 2.07:1 3rd Gear 1.43:1 4th Gear 1.00:1 5th Gear .71:1 6th Gear .57:1 Reverse Gear 3.28:1 Final Drive Ration 3.42 |
||||
| Hydra-Matic 2006 6L80 (MYC) Six Speed: |
1st Gear 4.03:1
2nd Gear 2.36:1 3rd Gear 1.53:1 4th Gear 1.15:1 5th Gear 0.85:1 6th Gear 0.67:1 Reverse Gear 3.06:1 Final Drive Ration 2.56 |
||||
| Standard Fuel Tank Capacity: | 18.0 Gallons / 68.0 Liters | ||||
| Battery, Cold Cranking Amps: | 590 | ||||
| Battery Replacement Model Number: | 86-3YR | ||||
| EPA Fuel Economy: |
Manual Transmission (Coupe, Convertible)
16 MPG (City) / 25 MPG (Highway) / 19 MPG (Combined) Automatic Transmission (Coupe, Convertible) 15 MPG (City) / 24 MPG (Highway) / 18 MPG (Combined) Manual Transmission (Z06) 15 MPG (City) / 24 MPG (Highway) / 18 MPG (Combined) Manual Transmission (ZR1) 14 MPG (City) / 21 MPG (Highway) / 17 MPG (Combined) |
||||
| Maximum Cruising Range - Coupe, Convertible: |
534.8 Miles (Manual Transmission)
477.5 Miles (Automatic Transmission) |
||||
| Weight: |
3,246 lbs / 1,473 kg (Convertible)
3,217 lbs / 1,459 kg (Coupe) 3,162 lbs / 1,434 kg (Z06) 3,350 lbs / 1,519 kg (ZR1) |
||||
| Weight Distribution: | 51% Front, 49% Rear | ||||
|
Passenger Compartment Air Filter Element:
(Coupe, Convertible, Z06) |
10345066 | ||||
|
|
| Designation: |
LS3 (Coupe, Convertible)
LS7 (Z06) LS9 (ZR1) |
| Type: | 90° V8, Pushrod, OHV (overhead Valve) |
| Displacement - Coupe, Convertible, ZR1: | 6.2 liters / 376 cubic inches (LS3) |
| Displacement - Z06: | 7.0 liters / 427 cubic inches (LS7) |
| Bore / Stroke - Coupe, Convertible: | 4.06 inches (101.62 mm) / 3.62 inches (92.0 mm) |
| Bore / Stroke - Z06: | 4.125 inches (104.8 mm) / 4.00 inches (101.6 mm) |
| Horsepower: |
430 hp @ 5,900 RPM (Coupe, Convertible LS3)
436 hp @ 5,900 RPM (Coupe, Convertible LS3 with optional exhaust) 505 hp @ 6,300 RPM (Z06 LS7) 638 hp @ 6,500 RPM (ZR1 LS9) |
| Torque: |
424 lbs. - ft. @ 4,600 RPM (Coupe, Convertible LS3 with standard exhaust)
428 lbs. - ft. @ 4,600 RPM (Coupe, Convertible LS3 with optional exhaust) 470 lbs. - ft. @ 4,800 RPM (Z06 LS7) 604 lbs. - ft. @ 3,800 RPM (ZR1 LS9) |
| Fuel Induction System: | Sequential Fuel Injection |
| Fuel Requirement - Coupe, Convertible: | Premium Recommended |
| Fuel Requirement - Z06, ZR1: | Premium Required |
| Coupe, Convertible, ZR1 Redline (RPM): | 6,500 |
| Z06 Redline (RPM): | 7,000 |
| LS3 Compression Ratio - Coupe, Convertible, Grand Sport: | 10.7:1 |
| LS9 Supercharger Pulley Ratio: | 2.3:1 |
| LS9 Maximum Boost: | 10.5 PSI |
| Compression Ratio - Z06: | 11.0:1 |
| Compression Ratio - ZR1: | 9.1:1 |
| Alternator: | 50 Amps (idle), 120 Amps Maximum |
| Cylinder Head Material: | Cast Aluminum |
| Exhaust Manifolds: | Stainless Steel |
| Main Bearing Caps: | Forged Steel |
| Crankshaft: | Forged Steel |
| LS9 Camshaft: | Hollow Steel; 0.555-in (14.1 mm) lift |
| LS9 Connecting rods: | Forged Titanium |
| LS9 Intake valves: | Titanium |
| LS9 Exhaust valves: | Hollow Steel |
| Supercharger: | R2300, four-lobe "Roots" type (2.3L) |
| Valve lifters: | Hydraulic Roller |
| Cylinder Block Material: | Cast Aluminum |
| Engine Oil Capacity - Coupe, Convertible: |
5.5 Quarts, with filter
5.0 Quarts, without filter |
| Engine Oil Capacity - Z06: |
8.0 Quarts, with filter
7.5 Quarts, without filter |
| Engine Oil Capacity - ZR1: | 12.5 Quarts, with filter |
| Recommended Oil: | 5W/30 Mobil 1 Synthetic or Equivalent |
| Recommended Oil Change Interval: | 15,000 miles or One Year, under normal use |
| Engine Oil Filter - Coupe, Convertible: | AC Delco Tyoe PF46 |
| Engine Oil Filter - Z06: | AC Delco Tyoe PF48 |
| Radiator Core Material: | Aluminum |
|
|
| Spark Plug Model - Coupe, Convertible: | AC P/N 41-985; GM Part No. 12571164 |
| Spark Plug Model - Z06: | AC P/N 41-104; GM Part No. 12571165 |
| Spark Plug Thread: | 14.0 mm |
| Spark Plug Tightening Torque: | 11 lb. ft / 15 N-m |
| Spark Plug Gap: | 1.0 mm (0.040 inch) |
| Spark Plug Wire Resistance: | 188 - 312 Ω |
|
|
| 0 - 60 MPH: | 3.4 seconds |
| 0 - 100: | 7.0 seconds |
| 0 - 1/4 mile: | 11.3 seconds (131 MPH) |
|
|
| Structure / Frame: | Integral Perimeter Frame with Center Backbone / All Welded Steel Body |
| Suspension - Front: | Independent SLA (Sort Long Arm) double wishbone cast aluminum upper and lower control arms, transverse mounted composite leaf spring, monotube shock absorber. |
| Suspension - Rear: | Independent SLA (Sort Long Arm) double wishbone cast aluminum upper and lower control arms, transverse mounted composite leaf spring, monotube shock absorber. |
| Steering: | Speed sensitive, magnetic power assisted rack and pinion |
| Steering Ratio: | 16.1:1 |
| Steering Turns, Lock to Lock: | 2.66 |
| Turning Circle, Curb to Curb: | 12.0 M / 39.4 ft. |
Brake Specs |
|
| Type: | Power Assisted, Four Wheel Vented Disc with Four Wheel ABS |
| Rotor, Front: |
Outer Working Diameter: (325 mm.) 12.8 inches
Thickness: (32 mm.) 1.26 inches |
| Rotor, Rear: |
Outer Working Diameter: (305 mm.) 12.0 inches
Thickness: (26 mm.) 1.0 inches |
| Rotor, Front - Z51 Performance Package: |
Diameter: (340 mm.) 13.4 inches
Thickness: (32 mm.) 1.26 inches |
| Rotor, Rear - Z51 Performance Package: |
Diameter: (330 mm.) 13.0 inches
Thickness: (26 mm.) 1.0 inches |
| Rotor, Front - Z06: |
Diameter: (355 mm.) 14.0 inches
Thickness: (32 mm.) 1.3 inches |
| Rotor, Rear - Z06: |
Diameter: (340 mm.) 13.4 inches
Thickness: (26 mm.) 1.0 inches |
| Rotor, Front - ZR1: | Diameter: 15.5 inches |
| Rotor, Rear - ZR1: | Diameter: 15.0 inches |
2012 Corvette Options
| RPO | Description | Production | Price |
| **6 | Modified Two Toned Seats w/Embroidery | 1,277 (10.96%) | $695.00 |
| 0B1 | Crossed Flag Headrest Embroidery | 1,081 (9.28%) | $300.00 |
| 28U | Inferno Orange Exterior Paint | 471 (4.04%) | $300.00 |
| 36S | Yellow Custom Stitch | 2,571 (22.07%) | $395.00 |
| 45U | Velocity Yellow Exterior Paint | 663 (5.69%) | $850.00 |
| 89U | Crystal Red Exterior Paint | 1,117 (9.59%) | $850.00 |
| B92 | Carbon Fiber Hood (Z06) | 119 (1.02%) | $1,495.00 |
| BA5 | Black Fender Badges, Grand Sport | 382 (3.28%) | $11,495.00 |
| C2L | Dual Removable Roof Panels (Coup) | 1,050 (9.02%) | $1,400.00 |
| CC3 | Transparent Roof Panel (Coup) | 1,048 (9.00%) | $750.00 |
| CFZ | Carbon Fiber Package (Z06) | 196 (1.68%) | $3,995.00 |
| D30 | Alternate trim / top / color combination | 58 (0.50%) | $590.00 |
| ERI | Battery Protection Package | 3,763 (32.31%) | $100.00 |
| F55 | Magnetic Select Ride (Grand Sport: $1,695; Z06: $2,495) | 4,778 (41.02%) | $1,995.00 |
| GLB | Supersonic Blue Exterior Paint | 893 (7.67%) | $300.00 |
| H33 | Headlamp Area - Gray | 548 (4.71%) | $590.00 |
| J55 | Cross Drilled Brake Rotors | 981 (8.42%) | $500.00 |
| J6C | Silver Brake Calipers | 8,769 (75.29%) | $595.00 |
| MYC | Six Speed Automatic Transmission | 7,586 (65.13%) | $1,250.00 |
| NPP | Dual Mode Exhaust | 6,664 (57.22%) | $1,195.00 |
| PBC | Engine Plant Build Experience (Z06, ZR1 only) | 12 (0.10%) | $5,800.00 |
| PDE | ZR1 Performance Package | 184 (1.58%) | $1,495.00 |
| PIN | Customer Selected VIN | 6 (0.05%) | $5,000.00 |
| PYD | Competition Gray Aluminum Wheels | 709 (6.09%) | $1,995.00 |
| PYE | Chrome Aluminum Wheels (Grand Sport) | 4,577 (39.30%) | $1,995.00 |
| Q44 | Competition Gray Aluminum Wheels | 42 (0.36%) | $395.00 |
| Q5V | Machine Face Cup Style Aluminum Wheel (Z06 / ZR1) | 54 (0.46%) | $995.00 |
| Q6B | Chrome 20 Spoke Aluminum Wheels (ZR1) | 101 (0.87%) | $2,000.00 |
| Q6J | Competition Gray Aluminum Wheels (ZR1) | 14 (0.12%) | $395.00 |
| Q8A | Spider Chrome Aluminum Wheels (Z06) | 103 (0.88%) | $1,995.00 |
| QX1 | Competition Gray Aluminum Wheels (Coupe / Convertible) | 221 (1.90%) | $395.00 |
| QX3 | Chrome Aluminum Wheels (Coupe / Convertible) | 1,441 (12.37%) | $1,850.00 |
| R8C | Corvette Museum Delivery | 181 (1.55%) | $490.00 |
| R8E | Gas Guzzler Tax (ZR1 Only) | 311 (2.67%) | $1,000.00 |
| RQ1 | Machine Faced Aluminum Wheel (Coupe / Convertible) | 321 (2.76%) | $895.00 |
| T43 | ZR1 Style Spoiler, Body Color | 1,542 (13.24%) | $350.00 |
| VK3 | Front License Plate Bracket | 7,140 (61.30%) | $15.00 |
| Z07 | Z06 Ultimate Performance Package | 117 (1.00%) | $7,500.00 |
| Z15 | Grand Sport Heritage Package | 1,034 (8.88%) | $1,195.00 |
| ZLC | Centennial Special Edition | 2,221 (19.07%) | $1,950.00 |
|
Total Production:
11,647
Notes: Base Corvette Coupe with 6.2L 376 cu. in. 430 hp engine and six speed manual transmission: $50,500.00. |
|||
2012 Packages |
||||
| RPO | Description | Contains | Production | Price |
| 2LT |
Equipment Group Convertible |
Includes navigation, Bose sound, bluetooth, USB port, heads up display. | 313 (2.69%) | $2,095 |
| 2LZ |
Equipment Group Z06 |
Includes navigation, Bose sound, memory package | 100 (0.86%) | $4,310 |
| 3LT |
Equipment Group Coupe |
Includes power telescoping steering column, memory package, heated sports seats, remote transmitter and cargo net shade. | 3,692 (31.70%) | $5,995 |
| 3LT |
Equipment Group Convertible |
Includes power telescoping steering column, memory package, heated sports seats, remote transmitter and power top. | 1,818 (15.61%) | $7,995 |
| 3LZ |
Equipment Group Z06 |
Includes custom leather, heated seats, two toned leather seats, embroidered head rests and special trim plate. | 274 (2.35%) | $8,815 |
| 3ZR |
Equipment Group ZR1 |
Includes bluetooth, power telescoping steering column, Bose sound, navigation, heated sport seats, remote transmitter, custom leather and memory package | 313 (2.69%) | $10,000 |
| 4LT |
Equipment Group Coupe |
Includes microfiber seat inserts, custom leather and trim plate | 414 (3.55%) | $9,495 |
| 4LT |
Equipment Group Convertible |
Includes microfiber seat inserts, custom leather and trim plate | 382 (3.28%) | $11,495 |
Colors
| Code | Exterior | Quantity | Interior | Soft Top | |
| 10 | Arctic White | 1,230 (10.56%) | |||
| 17 | Blade Silver | 1,302 (11.18%) | |||
| 28 | Inferno Orange | 471 (4.04%) | |||
| 45 | Velocity Yellow | 663 (5.69%) | |||
| 57 | Cyber Gray | 969 (8.32%) | |||
| 58 | Carbon Flash | 2,201 (18.90%) | |||
| 70 | Torch Red | 2,266 (19.46%) | |||
| 85 | Crystal Red | 1,117 (9.59%) | |||
| GLB | Supersonic Blue | 893 (7.67%) | |||
| GLF | Carlisle Blue | 535 (4.59%) | |||
Introducing the Vette Spotter app for the iPhone.
The Vette Spotter app can identify the year of any Corvette.
All years and generations are covered, from 1953 to 2014. Over 350 photographs and detailed text are included.
